HALDEX part description

Product Description

2S/1M Kit

Application Summary

Full kits do not include wheel end exciters. AL301220 junction cable needed for PLC 6S/4M multiple systems. Most ABS maintenance involves Wheel-end Sensors. Haldex recommends that Wheel-end Sensors be replaced when replacing or upgrading the ABS system.,Multi Complies with the March 2001 PLC4 Trucks industry. Kit includes detailed instructions for installation and maintenance.

Features & Benefits

  • Has new trailer placement and PLC Select ECU design
  • An FFABS valve type and reservoir mount
  • Designed with 3/8"-18 control port and 3/8"-18 emergency supply port
  • Built in compliance with the March 2001 PLC4 Trucks industry
  • Comes with detailed instructions for maintenance and installation
  • Specifically designed for use with ABS ready axles and builders power cord

Haldex FFABS Installation Kit

Maintenance and servicing of your fully functional ABS has never been easier with the Haldex FFABS installation kit. Manufactured by a brand with a solid reputation in manufacturing air brake system components, this kit already includes all the hardware you need to restore your air brake system’s like-new performance.

Product Attributes

Control Port Diameter 3/8 in.
Delivery Port Diameter 4 @ 3/8 in.
ECU / Valve Number N9001JB, N4306JD
ECU Design PLC Select
Freight Class 70
Kit Content (1) 20 x 12M Power Cord, (2) 2.5M Sensors (90°), and (1) Clips
Notes 4-Port FFABS Valve - Spring Brake Priority
Reservoir Port Diameter 1 @ 1/2 in., 1 @ 3/4 in. (Nipple)
Spring Brake Port Diameter 4 @ 3/8 in.
Supply Port Diameter 3/8 in.
Valve Type Full-Function ABS
Voltage 12V

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 8716905060
Harmonized Tariff Code (HTS) 8716905060
Remanufactured Part N
Warranty Distance 100000
Warranty Distance UOM MI
Warranty Special 36 MO, 200,000 MI=ABS - Antilock Braking Systems Including Haldex TRS (Valves, ECUs and Looms Only). 12 MO, 100,000 MI= All Other ABS - Antilock Braking Systems Components. See L20221W.pdf for warranty details
Warranty Time 12
Warranty Time UOM MO
UPC 00767653269405
VMRS Code 013011076

Part Interchanges

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.

HALDEX AQ960208 Cross Reference

We have 2 alternatives for the AQ960208 by HALDEX:
