(888) 312-8812 Login SignupEUCLID E-UB5161-14 Threaded U-Bolt, Round Bend, 4.00 in. Thread Length, 7/8 in.-14 Thread Size, Peterbilt 13-03440 Suspension
Tap to view 3 more
SHIPS TODAY
$4098
Package Price for 2 Units
@ $20.49 per unit
Limited availability at this price!
In Stock
Get it by Thursday, Sep 3
EUCLID E-UB5161-14 Part Description
Manufacturer
Product Description
U, Bolt Assy, Round Bend, 7/8, 14 Thd. X 3 W X 14 L
Euclid U-Bolt Assembly
The Euclid U-Bolt Assembly uses a round bend shape to clamp overslung spring suspension hardware on Peterbilt axle applications. Its Grade 5 construction, 7/8-inch-14 thread size, 3.00-inch width, and 14.00-inch length define a narrower spring-clamp package than the wider air-ride U-bolts used elsewhere in suspension work. The U-bolt body wraps the axle or spring seat while the nut side creates the draw-down force that holds the stack together. Old U-bolts often come off with stretched threads, rust scale, or distorted legs after years under clamp load, so reassembly works better with a fresh matched part. The Euclid E-UB5161-14 gives overslung spring service the correct round-bend hardware for the Peterbilt suspension position.
| Application | Springs Overslung - All Axles |
| Grade | 5 |
| Length | 14.00 in. |
| Notes | U-Bolt Assembly, Round Bend, 0.875 in.-14 Thd. x 3 in. Wide x 14 in. Long |
| Nut | E-3002A |
| Suspension Model | Peterbilt 13-03440 |
| Thread Diameter/Threads Per Inch | 7/8/2014 |
| Thread Length | 4.00 in. |
| Type | Round Bend |
| Type Number | 1 |
| VMRS Code | 016-005-007 |
| Washer | E-2546 |
Features & Benefits
- Round bend profile wraps the spring seat with the proper U-bolt shape
- Hardware matches the listed service requirement for this U-bolt assembly
| Thread | 7/8”–14” |
| A Dimension | 14" |
| B Dimension | 3" |
| C Dimension | 4" |
EUCLID E-UB5161-14 Specifications
Product Attributes
| Application | Springs Overslung - All Axles |
| Brand | Euclid |
| Grade | 5 |
| Length | 14.00 in. |
| Notes | U-Bolt Assembly, Round Bend, 0.875 in.-14 Thd. x 3 in. Wide x 14 in. Long |
| Nut | E-3002A |
| Pallet Quantity | 168 |
| Suspension Model | Peterbilt 13-03440 |
| Thread Length | 4.00 in. |
| Thread Size | 7/8 in.-14 |
| Type | Round Bend |
| Type Number | 01 |
| Washer | E-2546 |
| Weight | 5.42 |
| Width | 3.00 in. |
| Length | 14.00 in. |
| Grade Type | 5 |
| Thread Size | 7/8 in.-14 |
| Width | 3.00 in. |
EUCLID E-UB5161-14 Cross References
| Brand | Part Number |
|---|---|
| AUTOMANN | AUBK516114, AUB536114 |
| BWP | M1492 |
| DAYTON PARTS BATCO | 361218, 5U5313R, 361566K, 361577, 361577K |
| DAYTON-WALTHER | 39120014, 39120076, 39120085, 39120088 |
| FLAGG | UBK122, UBK1225 |
| Fruehauf | BXE000298901, BXE000298903, BXE000298902, MRM00849601D, MRM00849601S, UXA000046915, UXA000046916, UXA000046917 |
| GREAT DANE TRAILER | 704012 |
| HUTCHENS | 704005, 704006, 704007, 704008, 704009, 704011, 704012, 704013, 704014, 704010 |
| International | IT2366A, IT2368A |
| L AND H THREADED ROD | UB51410K, 51410K |
| NAPA | 65504 |
| NEW LIFE/FLEETCRAFT | 1014264KIT, 1014265KIT |
| PROVINCIAL WHSE -CAN | M6125 |
| REYCO | 7811, 007811K, 7812, 7813, 7814, 849101, 0849601K, 849201, 849301, 849401, 849501, 849601, 849001 |
| Reyco Granning | 7811, 007811K, 007812, 007813, 007814, 0849001, 0849101, 0849201, 0849301, 0849401, 0849501, 0849601, 0849601K |
| SIRCO BRAKE | 5R783146 |
| SPICER | H73000, H73035 |
| Trailmobile | 700326, 38UB516114 |
| WORLD AMERICAN | WA07-5013 |
| WORLD TRUCK | F1035 |
| Westar | 9515806 |
