GATES G25235-1012 Part Description
Manufacturer
Product Description
Female Flat-Face O-Ring Swivel - 45 Bent Tube (MegaCrimp)
Features & Benefits
- Robust "bite-the-wire" crimp
- Robust “bite-the-wire” crimp
- Tested to an industry-leading 1,000,000 impulse cycles
- Simplifies inventory management
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE Standard
GATES G25235-1012 Specifications
Product Attributes
| Coupling Description | MegaCrimp Female Flat-Face O-Ring Swivel - 45 Bent Tube |
| Industrial Description | 10G-12FFORX45S |
| Thread Size | 1 3/16-12 |
| Inside Diameter | .625 IN |
| Hydraulic Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Nut Hex Size | 36 MM |
| Drop Length | .83 IN |
| Cut-Off Length | 2.69 IN |
| Length | 4.17 IN |
| Seal Type | O-Ring |
| O-Ring Location | Flat Face O-Ring |
| Gender | Female |
| Bent Tube Angle | 45 |
| Swivel | Yes |
| Bulkhead | No |
| Inside Diameter | 15.9 MM |
| Drop Length | 21 MM |
| Cut-Off Length | 68.4 MM |
| Length | 105.9 MM |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Stock Status | S |
| UPC | 00072053173437 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G25235-1012 Cross References
| Brand | Part Number |
|---|---|
| Caterpillar | 124-2136 |
| Dayco | 108752 |
| Eaton | 10Z-L72 |
| Goodyear | 14710-1012, B2-OFFX45-1012 |
| Kurt Hydraulics | FFX45-10-12 |
| N/A | 04032292, E10-12FF45, M22443-10-12 |
| NAPA | G25235-1012 |
| Parker | 1J743-12-10, 1J7HY-12-10, 1J7HY-12-10-SM |
| Weatherhead | 10UL72, 10ZL72, 10U-L72 |
