Gates 68117 - PoweRated FHP Medium Horse-Power V-Belt
$5149
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
PoweRated FHP Medium Horse-Power V-Belt
Application Summary
Gravely, 40" Rotary, , Drive
Features & Benefits
- Designed with distinct green color bareback construction for smooth clutching on shock loaded, backside idler-driven equipment to ensure high crack resistance
- Low, aramid tensile cord positioned in a thin profile gives extreme flexibility and limited stretch with extraordinary strength and durability
- Meets RMA oil and heat-resistant standards, but not for static conductivity
- Temperature Range: -22 Deg. F to +140 Deg. F (-30 Deg. C to +60 Deg. C)
- Note: Gates PoweRated V-belts can be substituted for equivalent sizes of FHP low horsepower Gates Truflex V-belts
Product Attributes
| Type | FHP Medium Horse-Power V-Belt |
| Cross Section Designation | 4L |
| Angle | 37 |
| Strand Quantity | 1 |
| Top Width | .5 in |
| Outside Circumference | 117 in |
| Effective Length | 117 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Aramid |
| Top Width | 13 mm |
| Outside Circumference | 2972 mm |
| Effective Length | 2972 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | MX |
| UPC | 00072053434422 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
Part Interchanges
