GATES 22767 Part Description
Manufacturer
Product Description
Premium Molded Coolant Hose
Application Summary
2009-03 GMC, C7500, Isuzu 6HK1-TC Diesel, Upper - Eng. To Rad.
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
GATES 22767 Specifications
Product Attributes
| Centerline Length | 24.9 IN |
| Modular | No |
| Branch Quantity | 0 |
| Quick Connect Fitting Quantity | 0 |
| End 1 Inside Diameter | 1.75 in |
| End 2 Inside Diameter | 2 in |
| Contains Spring | No |
| Material | EPDM |
| Molded | Yes |
| Centerline Length | 632 MM |
| End 1 Inside Diameter | 44 MM |
| End 2 Inside Diameter | 51 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00072053794410 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
GATES 22767 Part Interchanges
| Brand | Part Number |
|---|---|
| ACDelco | 26436X |
| Carquest | 22767 |
| General Motors | 15096327, 15096332, 15797885 |
| Goodyear | 66944 |
| NAPA Belts/Hose | 9400 |
GATES 22767 Fits Vehicles
- Chevrolet C7500 Kodiak (2003-2009)
- Isuzu HXR (2006)
- Isuzu HVR (2005-2007)
- GMC C7500 Topkick (2003-2009)
- GMC C6500 Topkick (2003-2009)
- Chevrolet C6500 Kodiak (2003-2009)
- GMC C8500 Topkick (2003-2009)
- Chevrolet C8500 (2003-2009)
- Isuzu HTR (2005-2007)
GATES 22767 Cross References
We have 1 alternatives for the 22767 by GATES:
GATES 22767 Customer Reviews
No reviews yet
Be the first to review this product!
