Gates 20809 - Premium Molded Coolant Hose
$3099
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Premium Molded Coolant Hose
Application Summary
1976-1969 Chevrolet, Corvette, V-8 350, Upper
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation, the leading cause of hose failure
- Pre-shaped to fit and to ensure perfectly sealed conditions
- EPDM tube; synthetic fiber knit reinforcement; heat-, ozone- and chemical coolant-resistant EPDM cover
- Meets requirements of SAE 20R4, class D2 and DIN 73411, class A (except for tolerances)
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
Product Attributes
| Centerline Length | 19.6 IN |
| 9940 | No |
| Branch Quantity | 0 |
| 9845 | 0 |
| End 1 Inside Diameter | 1.5 in |
| End 2 Inside Diameter | 1.5 in |
| Contains Spring | No |
| Material | EPDM |
| 9839 | Yes |
| Centerline Length | 498 MM |
| End 1 Inside Diameter | 38 MM |
| End 2 Inside Diameter | 38 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| UPC | 00072053053227 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
Part Interchanges
- Canadian Tire 14-1869-6
- Motorcraft KM-903
- Motorcraft KM-1600
- Motorcraft KM-902
- Motorcraft KM-904
- Motorcraft KM-993
- ACDelco 24044L
- Dayco 70758
- Dayco 758
- Dayco E70758
- Dayco XE70758
- BF Goodrich MH495
- Carquest 20809
- Atlas (Canada) MH-968
- Continental Belt 66765
- Epton MH495
- General Motors 368685
- General Motors 3946852
- General Motors 3946856
- General Motors 3997761
- Ford D7OE 8B274 AB
- Ford D7OZ 8260 A
- Ultralast C0809
- Goodyear 66575
- NAPA Belts/Hose 7683
- Pro-1 P20809
- Duralast E70758
GATES 20809 Cross Reference
We have 2 alternatives for the 20809 by GATES:
Fits Vehicles
- Mercury Cougar (1977-1979)
- Ford Thunderbird (1977-1979)
- Ford Ranchero (1977-1979)
- Ford LTD II (1977-1979)
- Chevrolet Corvette (1969-1976)
