GATES part description

Product Description

Premium Molded Heater Hose

Application Summary

1998-1996 Ford, Mustang, V-8 4.6 L, Heater To Pipe-1

Features & Benefits

  • Has all the quality features of Gates molded coolant hose and similar to OEM specifications
  • Engineered to resist electrochemical degradation - the leading cause of hose failure
  • EPDM tube, synthetic fiber knit reinforcement, EPDM cover
  • Meets SAE 20R3 Type EC Class D-1 and D-2 specifications
  • Temperature Range: -40 Deg. F to 275 Deg. F (-40 Deg. C -135 Deg. C)
  • Note: Gates recommends replacing hose clamps each time a new coolant hose is installed
  • Caution: Do not use for fuel or oil transfer applications

Product Attributes

Centerline Length 12.4 IN
Branch Quantity 0
End 1 Inside Diameter .72 in
End 2 Inside Diameter .72 in
9845 0
Material EPDM
9839 Yes

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 4009310000
UPC 00072053294811
VMRS Code 042010004
UNSPSC 40142000

Part Interchanges

GATES 19690 Cross Reference

We have 1 alternatives for the 19690 by GATES:

Fits Vehicles

  • Ford Mustang (1996-1998)
