(888) 312-8812 Login SignupGATES 1293 Truflex FHP Low Horse-Power V-Belt
Tap to view 2 more
$999
Limited availability at this price!
5 Day Lead Time
Get it by Monday, Jun 22
GATES 1293 Part Description
Manufacturer
Product Description
Truflex FHP Low Horse-Power V-Belt
Application Summary
Montgomery Ward, TDZ135A, , Belt
Features & Benefits
- Flex-bonded cords are strongly forged to the belt body, resulting in equal load distribution, resistance to fatigue and shock loads and the absorption of bending stress without cord deterioration
- Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
- Runs with smooth, quiet operation
- Meets RMA oil and heat-resistant standards and static conductivity requirements
- Available in 2L (0), 3L (1), 4L (2) and 5L (3) cross-sections
- Do not use on applications where FHP medium horsepower V-belts are recommended
GATES 1293 Specifications
Product Attributes
| Type | FHP Low Horse-Power V-Belt |
| Cross Section Designation | 3L |
| Angle | 37 |
| Strand Quantity | 1 |
| Top Width | .38 in |
| Outside Circumference | 29.25 in |
| Effective Length | 28.98 in |
| Construction | Wrapped |
| Notched | No |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 10 mm |
| Outside Circumference | 743 mm |
| Effective Length | 736 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | MX |
| Stock Status | S |
| UPC | 00072053001310 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
