MONROE 39109 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- EXCEPTIONAL HANDLING -- Full displaced valving adjusts to road extremes to provide a smooth ride while free floating dividing piston separates fluid from high-pressure gas charging for reduced shock fade and aeration
- IMPROVES PERFORMANCE -- High pressure nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration and tight damping response provides vehicle control
- CONSISTENT RIDE -- High-temperature OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- MAINTAINS STABILITY -- Monotube technology maintains vehicle control over bumps, dips and potholes for vehicles originally equipped with monotube shocks and struts
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and high-strength pressure tube for better control, increased durability and longer service life
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 39109 Specifications
Product Attributes
| Lower Mount Code | LS8 |
| Upper Mount Code | S15 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 18.5 IN |
| Extended Length | 20.71 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 10MM Sleeve ID X 2" Sleeve OAL |
| Parts Pack(s) | BE17110326 |
| Travel Length | 2.21 in |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X M10 Thread Pitch |
| Compressed Length | 469.9 MM |
| Extended Length | 526 MM |
| Travel Length | 56.1 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS8 |
| Upper Mount Code | S15 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | PL |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598076717 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 39109 Cross References
| Brand | Part Number |
|---|---|
| 39109ST, FT4Z5841308AB | |
| KYB | 553356 |
| KYB AMERICA LLC. | 553380 |
| Mercedes-Benz | 2103200913, 2103203330, 2103236000, 2113200631, 2113200731, 2113200831, 2113205413, 2113205513, 2113206013, 2113206113, 2113235600, 2113235700, 2113236500, 2113236600, 2113237900, 2113238000, 2113239200, 2113239300, 2113239400, 2113260100, 2113260200, 2113261100, 2113261200, 2113261500, 2113261600, 2113262800, 2113263200, 2113263600, 2113263800, 2113264100, 2113264300, 2113264400, 2113265200, 2113265400 |
| Monroe Shocks & Struts | 210386 |
| NAPA Shocks | 39109 |
| VAICO | V301709, V30-2156, V30-2157, V30-1703 |
| VEMO | V30500030, V30500031 |
MONROE 39109 Fits Vehicles
- Mercedes-Benz E350 (2006-2009)
- Mercedes-Benz E500 (2003-2006)
- Mercedes-Benz E320 (2003-2009)
