FRAM PH9100 - Full-Flow Spin-On Lube Oil Filter
$749
MSRP: $9.42
Save: $1.93
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
FRAM part description
Product Description
FRAM, PH9100, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- SureGrip® technology for easy install and removal
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- Silicone anti-drain back valve helps ensure safe engine start up
Spin-on Oil Filter
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 5.125 IN |
| Anti-Drain Back Valve | Yes |
| Bypass Relief Valve | Yes |
| Filter Type | Spin-On Canister |
| Gasket Thickness | 0.225 IN |
| Housing Color | Orange |
| Non Slip Grip | Yes |
| Torque Nut | No |
| Gasket Inside Diameter | 3.109 IN |
| Gasket Outside Diameter | 3.453 IN |
| Attachment Type | Spin-On |
| Burst Pressure | 230.000 PS |
| Bypass Relief Valve Setting | 9-15 PS |
| Gasket Type | Base |
| Grade | Advanced |
| Grade Type | Regular |
| Inlet Type | Threaded |
| Inside Thread Diameter | 13/16-16 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| Outside Diameter | 3.660 IN |
| Replacable Filter | Yes |
| Reusable | No |
| Thread Size | Standard |
| Burst Pressure | 230.000 PS |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100028044 |
| UNSPSC | 15121501 |
Part Interchanges
- Champ LFP2999
- Bosch 3511
- Donaldson P550518
- Casite Filters CF524
- Hastings LF524
- K&N HP-3003
- Pennzoil PZ-59
- Group 7 V5399
- Ultra XG9100
- ACDelco PF2232
- Purolator L35399
- Quaker State L35299
- Wix 57202
- Auto Extra 61857202
- Baldwin B1441
- LUBER-FINER LFP2999
- Carquest 84202
- Service Champ OF5399
- VIPER 9100
- Amsoil EAO52
- Shell - Archived SH49
- Mann-Filter ML 1035
- Certified CPH9100
- Fleetguard LF16102
- General Motors 87214983
- Warner LFP2999
- Isuzu 8-97214-983-1
- Champion 47202T
- Parts Plus LFP2999
- Mobil 1 M1-303
- Installer Edge AL9100
- Mileguard MO9100
- Pronto PO-5399
- MicroGard MGL9100
- Pentius PLB9100
- Pit Stop PSL46
- Silverline 27202
- Performax PO-59
- MotoMaster MPH9100
- Driveworks DW-5399
- Valvoline VO-75
- Defense Filters DL9100
- STP S9100
- Parts Master 67202
- NAPA 7202
- Purolator BOSS PBL35399
- FVP R7202
- Tough Guard TG9100
- Mobil MO5399
- Hastings LF524F
- K&N PS-3003
- Pennzoil PZ59
- Quaker State QS9100
- Carquest R84202
- Carquest R84202MP
- General Motors 88917036
- General Motors 97214983
- Champion COS9100
- Mobil 1 M1-303A
- Parts Master 67202BP
- Carquest Premium Filters 84202
- Mighty Distributing System M2999
- Promotive PH5399
- Factory Motor Parts R7202
- Magneti Marelli 1AMFL00012
- STP Filters S9100
- MicroGard MGL57202
- NAPA Gold Filters 7202
- Premium Guard PG5399
- Champion Filters 47202T
- Purolator PureONE PL35399
- ECOGARD X5399
- Prime Guard Filters - Archived POF5399
- NAPA Platinum Filters 47202
- Warner Filters LFP2999
- PureZone 8-57202
- Purolator TECH TL35399
- PurolatorONE PL35399
- FRAM Tough Guard TG9100
- FRAM Ultra Synthetic XG9100
- FRAM Force FF9100
- FRAM Titanium FS9100
- FRAM Drive FD9100
- FRAM Synthetic Endurance FE9100
- Wix 57202XP
- Parts Master 67202X
- Champion Filters COS9100
- Champ LFP2999XL
- Installer Edge ML9100
- MicroGard Select MSL57202
- STP Filters S9100ML
- STP Filters S9100XL
FRAM PH9100 Cross Reference
We have 8 alternatives for the PH9100 by FRAM:
Fits Vehicles
- Suzuki Aerio (2002)
- GMC Sierra 3500 Classic (2007)
- Chevrolet Silverado 3500 Classic (2007)
- GMC Sierra 2500 HD Classic (2007)
- Chevrolet Silverado 2500 HD Classic (2007)
- Chevrolet Express 4500 (2009-2016)
- GMC Savana 4500 (2009-2016)
- Chevrolet Silverado 3500 HD (2007-2019)
- Chevrolet Express 3500 (2006-2016)
- Chevrolet C4500 Kodiak (2003-2009)
- GMC Sierra 3500 HD (2007-2019)
- GMC Savana 2500 (2006-2016)
- GMC Savana 3500 (2006-2016)
- Chevrolet C5500 Kodiak (2003-2009)
- GMC C5500 Topkick (2003-2009)
- Hummer H1 (2006)
- GMC C4500 Topkick (2003-2009)
- Chevrolet Express 2500 (2006-2016)
- GMC Sierra 2500 HD (2001-2019)
- GMC Sierra 3500 (2001-2006)
- Chevrolet Silverado 3500 (2001-2006)
- Chevrolet Silverado 2500 HD (2001-2019)
