FRAM PH4386 Part Description
Manufacturer
Features & Benefits
- Anti-slip coating assists proper handling when servicing in confined areas
- Seal structure helps reduce leakage risk during warm-weather expansions
- Internal support mesh contributes structural consistency across changing load conditions
- Valve assembly manages oil routing during abrupt throttle input
Fram Full-Flow Spin-On Lube Oil Filter
The Fram Full-Flow Spin-On Lube Oil Filter is frequently installed on vehicles used for extended weekend excursions where roads vary from open highway stretches to slower scenic routes. Its ability to manage shifts in oil temperature helps keep lubrication flowing when engines alternate between long steady cruising and brief climbs through hilly regions. The exterior grip surface offers traction for filter changes performed in tight garage spaces or improvised roadside situations. This model pairs well with both high-mile synthetic blends and more traditional oil selections, supporting engines that see inconsistent driving rhythms throughout the year. The Fram PH4386 contributes oil clarity for drivers who regularly move between relaxed travel and prolonged highway movement.
FRAM PH4386 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 3.469 IN |
| Anti-Drain Back Valve | Yes |
| Bypass Relief Valve Setting | 14 PS |
| Bypass Relief Valve | Yes |
| Filter Type | Spin-On Canister |
| Gasket Thickness | 0.281 IN |
| Housing Color | Orange |
| Non Slip Grip | Yes |
| Torque Nut | No |
| Gasket Inside Diameter | 2.250 IN |
| Gasket Outside Diameter | 2.500 IN |
| Attachment Type | Spin-On |
| Burst Pressure | 350.000 PS |
| Gasket Type | Base |
| Grade | Advanced |
| Grade Type | Regular |
| Inlet Type | Threaded |
| Inside Thread Diameter | 3/4-16 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| Outside Diameter | 2.688 IN |
| Replacable Filter | Yes |
| Reusable | No |
| Thread Size | Standard |
| Burst Pressure | 350.000 PS |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100381996 |
| UNSPSC | 15121501 |
FRAM PH4386 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 041-8065, 041-8066, 041-8079, 041-8102 |
| Champ | PH2840, PH2840XL |
| Bosch | 3311, 72166, 72176, D3311, D3325 |
| Flag | C-4967, C-3614 |
| Casite Filters | CF413 |
| Hastings | LF308, LF308F, LF413, LF413F |
| K&N | HP-1003, PS-1003 |
| Pennzoil | PZ-38, PZ38, PZ38BP |
| Promotive | SL14476 |
| Group 7 | V4476 |
| Sierra | 18-7895, 18-7896 |
| ACDelco | 88969580, PF1233, PF1234, PF1238, PF2052, PF2228, PF2246, PF53, PF53CL, PF53FCL |
| Kralinator | L4 |
| Purolator | L14477, PSL14477 |
| Quaker State | QS4386, QS4386BLK |
| Auto Extra | 61851396 |
| Big A | 92396 |
| Castrol | CAS4967 |
| Firestone | TF4477 |
| Baldwin | B1406, B37, B7119 |
| LUBER-FINER | PH2840 |
| OE+ | OF-460, OF-470 |
| Professionals Choice - Archived | Q4477 |
| Carquest | 84145, 84530, 85396, B4477, R84145 |
| Service Champ | OF4477 |
| Amsoil | EAO10 |
| Shell - Archived | SH525 |
| Mann-Filter | ML 1017, W610/80, W610/83 |
| Cam2 | C4477 |
| Cenex | CO2823, CO2841 |
| Certified | CPH4386 |
| Crosland | 2100 |
| Daihatsu | L14477, 15601-87705-000 |
| Deutsch | D369, D372 |
| Deutz-allis | 72101498 |
| Evergard | E4477 |
| Fleetguard | LF3615, MK13083 |
| Generac | 070185E, 070185ES, 070185F |
| General Motors | 88969580, 89060466, 89060498, 91173772, 91176161, 94845246, 94848478, 94851858, 9484246 |
| Suzuki | 16510-61A00, 16510-61A01, 16510-61A02, 16510-61A20, 16510-61A20-MHL, 16510-61A21, 16510-61A30, 16510-61A31, 16510-61AV1, 16510-82703, 16510-93J00 |
| Champion | 47145T, COS4386 |
| Parts Plus | PH2840 |
| Kendall | K33 |
| Mobil 1 | M1-103, M1-103A |
| IAPCO | OF22, OF4 |
| Installer Edge | AL4386, ML4386 |
| Jiffy Lube | HL4386, JL4477, L14477 |
| Lazorlite | L11-1910, L11-1929 |
| Mileguard | MO4386, MO4967 |
| Pronto | PO-4386, PO-4476 |
| OMC | 5033919, 5035703, 778887, 778888 |
| MicroGard | MGL4967, MGL57530, MGL57145 |
| Pentius | PLB4386 |
| Pit Stop | PSL33 |
| Power Flo | SL10241, SL14477 |
| Service Pro | M4477 |
| Silverline | 21396 |
| Performax | PO-38 |
| Sunoco | O-34 |
| NAPA ProSelect Filters | 27145, 27530 |
| Lee | LF-2841, LF-2841HP |
| MotoMaster | MPH4386 |
| Grand Prix | PH2823, PH2841 |
| Master Parts | PH-2841 |
| Goodyear | L4477 |
| Defense Filters | DL4386 |
| STP | S4967 |
| Parts Master | 67145, 67145BP, 67530 |
| DENSO | 115010-1390, 115010-1660, 150-1001, 150-1015 |
| MAHLE | OC1042, OC217, OC217/6, OC218 |
| Atlas | M-40 |
| NAPA | 1396, 7145, 7530 |
| Grease Monkey | GM14477, GM4477 |
| Nissan | 15208-53J00 |
| IPD | 10129 |
| Havoline | TFC-525 |
| Purolator BOSS | PBL14476, PBL14477 |
| SUPERTECH | ST4386, ST4967 |
| PurolatorONE | PL14476, PL22821, PL14477 |
| FVP | F2840 |
| ITM | 11-11518 |
| Mobil | MO4477 |
| Car Care | IOF4386, OF4536 |
| Donaldson | P502019, P551255 |
| Web | W4386 |
| Filters Inc | OF4386 |
| Wix | 51389, 51396, 57145, 57145XP, 57530 |
| Canada Tire | 17-1724-4 |
| Pro-Gauge | PGO-4477 |
| Trust | PH2841 |
| VIPER | 4386 |
| Mahle | OC1042, OC217, OC217/6, OC218 |
| Citgo Petroleum | C4477 |
| Econo-lube | L14477 |
| Factory Motor Parts | F2840 |
| Girling | F6588, F6603, F6613, F6622 |
| Magneti Marelli | 1AMFL00007 |
| Toyota | 08922-02001, 15600-16010, 90915-03004, 90915-10002, 90915-10004, 90915-10010, 90915-TA002, 90915-YZZA2, 90915-YZZE2, 90915-YZZF1 |
| STP Filters | S4967 |
| Tokyo-Roki | LFS708 |
| Unocal 76 | PF2875 |
| NAPA Gold Filters | 7145 |
| Valvoline | VO-40, VO-40BP, VO-41 |
| TCI Automotive | C0120-00014 |
| Champion Filters | 47145T, COS4386 |
| Purolator PureONE | PL14476, PL22821 |
| Security Filters | SO2823, SO2841 |
| ITM Autoparts | 11-11518 |
| NAPA Platinum Filters | 47145 |
| Volvo Penta | 861473, 861473-7 |
| Warner Filters | PH2823, PH2840, PH2841 |
| Super Tech Filters | ST4386, ST4967 |
| PureZone | 8-57145, 8-57530 |
| Purolator TECH | TL14477 |
| FRAM Tough Guard | TG4386 |
| FRAM Ultra Synthetic | XG4386 |
| FRAM Core | COR4967ACC |
| FRAM Force | FF4386 |
| FRAM Titanium | FS4386 |
| FRAM Drive | FD4386 |
| FRAM Pro | FP4967BP |
FRAM PH4386 Fits Vehicles
- Lexus GX550 (2024-2025)
- Lexus RX350h (2023-2025)
- Lexus RX500h (2023-2024)
- Toyota Sequoia (2023-2025)
- Toyota Tundra (2022-2024)
- Lexus LX600 (2022-2024)
- Lexus LS500 (2018-2024)
- Suzuki SX4 Crossover (2012)
- Suzuki Grand Vitara (2011-2013)
- Scion tC (2009-2010)
- Suzuki Kizashi (2010-2013)
- Scion xB (2008-2015)
- Toyota Matrix (2009-2013)
- Suzuki SX4 (2007-2013)
- Toyota Solara (2002-2008)
- Toyota RAV4 (2004-2008)
- Pontiac Vibe (2005-2006, 2009-2010)
- Toyota MR2 (1988-1989, 1991-1995)
- Nissan NX (1991-1993)
- Toyota Camry (2002-2011)
- Toyota Corolla (1988-1991, 2009-2013)
- Toyota Celica (1990-1993, 2000-2001)
- Toyota Highlander (2002-2007)
- Nissan Sentra (1991-1994)
- INFINITI G20 (1991-1996)
- Geo Prizm (1990-1992)
- Chevrolet Nova (1988)
- Chevrolet Tracker (1999-2003)
- Daihatsu Charade (1988)
- Suzuki Sidekick (1989, 1996-1998)
- Suzuki Swift (1989, 2001)
- Suzuki Aerio (2002-2007)
- Suzuki Vitara (1999-2003)
- Suzuki Samurai (1990-1995)
- Suzuki Esteem (1999-2002)
FRAM PH4386 Cross References
We have 11 alternatives for the PH4386 by FRAM:
