(888) 312-8812 Login SignupWEATHERHEAD 3270-0613-0100 Synflex 3270 Series Airbrake Hose and Tubing
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WEATHERHEAD 3270-0613-0100 Part Description
Manufacturer
| Product Name | Eaton Synflex 3270 Series Airbrake Hose and Tubing |
| Compliances | DOT FMVSS 106 |
| Certifications | SAE J844 SAE J1131 SAE J2494-2 |
| Construction | 1 Ply Braid |
| Tube material | Nylon |
| Color | Orange |
| Conductivity | Non-Conductive |
| Dash size | -6 |
| Abrasion resistance | Premium |
| Working temperature - min | -40 F |
| Working pressure | 350 Psi |
| Lay line style | Ink Jet |
| Outside diameter | .375 IN |
| Reinforcement material | Synthetic fiber |
| Inside diameter | .25 IN |
| Cover material | Polyester |
| Tube wall thickness | .06 IN |
| Bend radius - min | 1.5 IN |
| Burst pressure | 1400 Psi |
| Impulse cycle life | 125000 Cycles |
| Application | Truck air brake systems, trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies. |
| Working temperature - max | 200 F |
WEATHERHEAD 3270-0613-0100 Customer Reviews
No reviews yet
Be the first to review this product!
WEATHERHEAD 3270-0613-0100 Manufacturer Information
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
