FRAM C9031 Part Description
Manufacturer
Product Description
FRAM, C9031, Hydraulic Filter
Internal Transmission Cartridge Filter
FRAM C9031 Specifications
Product Attributes
| Universal Or Specific Fit | Specific |
| Bottom Outside Diameter | 3.000 in |
| Filter Type | Cartridge |
| Fuel Type | Hydraulic |
| Gasket or Seal Included | Yes |
| Grade Type | Regular |
| Height | 5.938 in |
| Housing Color | NA |
| Inner Diameter Bottom | 1.500 in |
| Mounting Type | Cartridge |
| New Or Remanufactured | New |
| O-ring Inside Diameter | 0.641 IN |
| O-ring Inside Diameter (1) | 3.406 IN |
| O-ring Inside Diameter (2) | 3.031 IN |
| O-ring Outside Diameter | 0.812 IN |
| O-ring Outside Diameter (1) | 3.688 IN |
| O-ring Outside Diameter (2) | 3.171 IN |
| O-ring Thickness | 0.125 IN |
| O-ring Thickness (1) | 0.094 IN |
| O-ring Thickness (2) | 0.063 IN |
| Outside Diameter Top | 3.000 in |
| Reusable | No |
| Top Inside Diameter | 1.500 in |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8421290065 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100028518 |
| UNSPSC | 40161807 |
FRAM C9031 Cross References
| Brand | Part Number |
|---|---|
| AC-DELCO | PF1280 |
| ACDelco | PF1280 |
| ALLIANCE | ABP/N10G-29540494 |
| ALLISON | 29506337, 29526898, 29540494, 29545779, 29545780 |
| ATP TRANSMISSION PARTS | B-204 |
| Alliance Truck Parts | ABP/N10G-29540494 |
| BALDWIN | PT8405-MPGKIT, PT8515-MPGKIT, PT9415-MPG KIT |
| Baldwin | PT8515-MPG KIT, PT9415-MPGKIT |
| Big A | 91740, 91740XE |
| Carquest | 84740, 84740XE |
| Demag | 42004612 |
| Donaldson | P179096, P560971 |
| Fleetguard | HF28937, HF28943 |
| Fleetrite | HFR828943 |
| General Motors | 29506337, 29509723, 29526898, 29540494, 29545779 |
| Hastings | HF1005, HF968, HF998 |
| Kralinator | L7740 |
| LUBER-FINER | LH4582G, LH4907G |
| MAIN FILTER | MF0696272 |
| NAPA | 7740, 7740XE |
| Nelson | 99252K, 99279K |
| Purolator | H35963 |
| WIX FILTERS | 57740XE |
| Wix | 57740, 57740XE |
FRAM C9031 Fits Vehicles
- Kenworth T700 (2011-2015)
- Kenworth T880 (2014-2018)
- Kenworth T680 (2013-2017)
- Kenworth T660 (2008-2017)
- Kenworth C500 (2002, 2005-2012)
- Kenworth T400 (2010-2017)
- Peterbilt 340 (2007-2010)
- Kenworth T170 (2014-2016)
- Freightliner B2 (2005-2008)
- Kenworth W900 (1999-2016)
- Kenworth T600A (2002-2007)
- Kenworth T2000 (2002-2011)
- Kenworth T800 (1999-2017)
- Freightliner 114SD (2012-2017)
- Freightliner 108SD (2012-2017)
- Freightliner Cascadia (2008-2015)
- Freightliner Business Class M2 (2004-2012)
- Freightliner Classic (2001-2011)
- Freightliner Argosy (2000)
- Freightliner FL80 (1999-2005)
- Freightliner FC80 (1999-2005)
- Freightliner FC70 (1999-2003)
- Freightliner FL70 (1995-2005)
- Freightliner Century Class (1996-2011)
- Freightliner FL60 (1995-2004)
- Kenworth T270 (2008-2017)
- Kenworth T370 (2008-2017)
- Kenworth T300 (1995-2008)
- Freightliner FS65 (1997-2008)
- Freightliner FL50 (1995-2004)
- Peterbilt 330 (1995-2005, 2007-2013)
- Peterbilt 335 (2005-2010)
- Suzuki Aerio (2002)
- Hino 358 (2008-2017)
- GMC C8500 Topkick (2004-2009)
- Isuzu HXR (2006)
- Isuzu FXR (2004)
- Chevrolet T8500 (2004-2009)
- Ford AT9522 (1997-1998)
- Ford AT9513 (1996-1998)
- Ford A9522 (1997)
- Ford A9513 (1996-1998)
- American LaFrance ALF Eagle (1997-2009)
- Gillig Low Floor (2003-2005)
- Isuzu HVR (2005-2008)
- Isuzu HTR (2005-2008)
- Isuzu FRR (2000-2004)
- Hino SG3325 (2004)
- Isuzu FTR (1998-2009)
- Isuzu FVR (1998-2011)
- Ford F750 (2000-2010)
- Ford F650 (2000-2010)
- GMC T7500 (1998-2002, 2004-2009)
- GMC T6500 (1998-2002, 2004-2009)
- Chevrolet T7500 (1998-2002, 2004-2009)
- Chevrolet T6500 (1998-2002, 2004-2009)
- Hino 338CT (2008-2014)
- Mitsubishi Fuso FM330 (2005-2011)
- Hino 338 (2005-2017)
- GMC C7500 Topkick (2003-2009)
- GMC C6500 Topkick (2003-2009)
- Chevrolet C7500 Kodiak (2003-2009)
- Chevrolet C6500 Kodiak (2003-2009)
