(888) 312-8812 Login SignupWABCO 4324251010 Air Brake Dryer - Electrically Controlled, Air System Protector Plus M39
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WABCO 4324251010 Part Description
WABCO 4324251010 Specifications
Product Attributes
| Temperature Range | -40°C to +65°C |
| Cartridge Type | Air System Protector Plus M39 |
| Weight | 8.71 |
| Calculated Volume (dm³) | 7.7097 |
| Port Thread 4/23 | 1/4" - 18 NPTF |
| Opening Pressure | 13.00 bar |
| Solenoid Connection | Bayonet DIN 72585 A2-4.1-Sn/K1 |
| Port thread 21 | M22 x 1.5 JED - 388-4 |
| Exhaust | Thread female M 22x1.5 |
| Heating System | Yes |
| Size | 293 x 179 x 147 |
| Voltage | 24 V |
| Silencer | 432 407 060 0 |
| Max. operating pressure | 13.0 bar |
| Heating Connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Electrical connection | DIN 72585 A1-2.1-1-Sn/K1 |
| Port thread 12 | M16 x 1.5 |
| Port thread 1 | M22 x 1.5 JED-388-4 |
| Unloader | No |
WABCO 4324251010 Cross References
WABCO 4324251010 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4324251010 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
