WABCO 4324100350 - Air Brake Dryer - Single Cannister, Desiccant Cartridge, 188.5 psi
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
WABCO part description
Air Dryer, Single Cannister
Product Attributes
| Operational Range | 0.7+0.6 bar |
| Voltage | 24 V |
| Size | 259 x 187 x 154 |
| Heater | 894 260 049 2 |
| Heating Connection | Bayonet DIN 72585-A1-2.1-1-Sn/K2 |
| Max. operating pressure | 13.0 bar |
| Port thread 22 | M12 x 1.5 |
| Port Thread 4/23 | M12 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Unloader | Yes |
| Weight | 7.363 |
| Temperature Range | -40°C to +65°C |
| Silencer | No (432 407 012 0 retrofittable) |
| Cartridge Type | Desiccant Cartrige |
| Exhaust | Snap-on contour |
| Calculated Volume (dm³) | 7.459 |
| Port thread 1 | M22 x 1.5 |
| Cut-Out Pressure | 11 bar |
WABCO 4324100350 Cross Reference
We have 15 alternatives for the 4324100350 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
