CENTRIC 125.34043 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.34043 Specifications
Product Attributes
| Weight [cntrc] Kgs | 7.690 |
| Weight [cntrc] Lbs | 16.920 |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 2 |
| Discard Thickness | 18.400 MM |
| Discard Thickness | 0.724 IN |
| Nominal Thickness | 19.800 MM |
| Nominal Thickness | 0.780 IN |
| Hat Finish | Painted |
| Overall Height | 61.000 MM |
| Overall Height | 2.402 IN |
| Outside Diameter | 328.000 MM |
| Outside Diameter | 12.913 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
| Bearings Included | No |
| Center Hole Diameter | 75.000 MM |
| Center Hole Diameter | 2.953 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.579 IN |
| Stud/Lug Hole Diameter | 14.700 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | IT |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890765769 |
CENTRIC 125.34043 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD180107, 0832670, 420182, 6412570, 34068, 25730, 34068G, 34211160233, 34216751194, 34216767062, PRT5131, 145131, 96770P, 86770, EBR476, 90031041, 150.1281.00 |
| RAYBESTOS | 96770 |
| Raybestos Brakes | 96770 |
CENTRIC 125.34043 Fits Vehicles
- BMW 750iL (1995-2001)
- BMW Z8 (2000-2003)
