Centric 128.35077 - Centric Premium OE Style Drilled Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium OE Style Drilled Brake Rotor
Features & Benefits
- Premium rotors feature 100% fully machined finishes including rotor hats. This extra process provides better rotor balance and creates a cleaner; more finished looking component
Product Attributes
| Vane Style [cntrc] | Curved |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 21.000 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Kgs | 9.550 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 24.000 MM |
| Discard Thickness | 0.945 IN |
| Nominal Thickness | 1.024 IN |
| Nominal Thickness | 26.000 MM |
| Hat Finish | Coated |
| Overall Height | 68.400 MM |
| Overall Height | 2.693 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | X Drilled |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 7.047 IN |
| Nominal Drum Diameter | 179.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67.000 MM |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.000 MM |
| Stud/Lug Hole Diameter | 0.591 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890656128 |
Part Interchanges
CENTRIC 128.35077 Cross Reference
We have 1 alternatives for the 128.35077 by CENTRIC:
Fits Vehicles
- Mercedes-Benz E63 AMG (2007-2009)
- Mercedes-Benz CLS63 AMG (2007-2011)
- Mercedes-Benz CLS55 AMG (2006)
- Mercedes-Benz E55 AMG (2003-2006)
