Name: Donaldson M085056 Exhaust Muffler - 25.00 in. Overall length
SKU: m085056
Price: 443.49 USD
Availability: InStock

DONALDSON part description

Product Description

MUFFLER, ROUND STYLE 2

Product Attributes

Body Length	20.25 in
Overall Length	25.00 in
Attenuation Hr	20 dBA
Attenuation Lr	15 dBA
Back Pressure High-range	Hg2.99 inch Hg)
Back Pressure Low-range	Hg0.98 inch Hg)
Back Pressure Mid-range	Hg2.01 inch Hg)
Body Diameter Maximum	8.46 in
Inlet Clock Position	12/31/1899 6:00:00 AM
Inlet Diameter	3.02 in
Outlet Clock Position	12/31/1899 12:00:00 PM
Outlet Diameter	3.02 in
Rated Flow Hr	31 m³/min (1095 cfm)
Rated Flow Lr	17.9 m³/min (632 cfm)
Rated Flow Mr	25.3 m³/min (893 cfm)
Style	Style 2
