DONALDSON part description

Product Description

MUFFLER, ROUND STYLE 1

Product Attributes

Body Length 12.19 in
Overall Length 17.00 in
Attenuation Hr 15 dBA
Attenuation Lr 10 dBA
Back Pressure High-range Hg2.99 inch Hg)
Back Pressure Low-range Hg0.98 inch Hg)
Back Pressure Mid-range Hg2.01 inch Hg)
Body Diameter Maximum 7.99 in
Inlet Diameter 3.02 in
Outlet Diameter 3.13 in
Rated Flow Hr 23.6 m³/min (833 cfm)
Rated Flow Lr 13.6 m³/min (480 cfm)
Rated Flow Mr 19.3 m³/min (682 cfm)
Style Style 1
For more than 100 years, Donaldson® has provided effective solutions to complex filtration challenges in various industries. Fleet managers worldwide have relied on Donaldson’s wide range of filtration products to ensure their trucks operate at peak efficiency and reduce expenses and maintenance downtime in the long run. These products include air intake filters and cleaners, cabin air filters, coolant filters, fuel filters and water separators, transmission filters, exhaust filtration products, and so much more. Each Donaldson filtration product is engineered for durability and performance that matches that of the original. Whether they are long-haul trucks, school buses, dump trucks, or other commercial vehicles, Donaldson filtration products will help keep them running smoothly.
