BENDIX 3558072X Part Description
Manufacturer
Product Description
Compressor
Features & Benefits
- Remanufactured unit renews the compressor without replacing downstream charging hardware
- Builds the compressed-air supply used by the dryer and reservoirs
- Engine-side compatibility remains essential for mounting and drive alignment
- Concentrates service on the worn air-generation component instead of the full system
Bendix Air Brake Compressor
For fleets that want to renew the compressor without changing the surrounding charging-system architecture, the Bendix Air Brake Compressor offers a remanufactured service option. Because the surrounding charging hardware can remain installed when it is still serviceable, the remanufactured compressor concentrates the work at the engine-driven air source. Before installation, engine compatibility, drive interface, mounting position, and air-line connections should be checked together because each one affects how the compressor integrates with the existing setup. The Bendix 3558072X therefore belongs at the source of system air generation, not at a downstream control point.
BENDIX 3558072X Specifications
Product Attributes
| Air Discharge Port | Front |
| Air Inlet Port | Right |
| Bore Size | 92.1 mm |
| Compressor Drive Type | Spline |
| Compressor Manufacturer | Holset |
| Coolant Inlet Port | Front |
| Cooling | Water-Cooled |
| Crankshaft Drive Type | Threaded |
| Displacement (CFM at 1250 RPM) | 13.2 CFM |
| Drive Gear Included | Not applicable to this part |
| Engine Manufacturer | Cummins |
| Engine Model | L10 / N14 |
| Governor Included | No |
| Lubrication | Drive Flange Oil Feed |
| Market Indicator | Aftermarket Remanufactured |
| Mounting Flange Location | Flange, Front |
| Number of Cylinders | 1 |
| Number of Mounting Holes | 4 |
| Thru-Drive Mounting Type | Flange - 4 Hole |
| Thru-Drive Shaft Connector | 3-Prong |
Additional Information
| Core Class | JC |
| Core Group | J3 |
| Country of Origin (Primary) | US |
| UPC | 07894294732432 |
| VMRS Code | 013009001 |
BENDIX 3558072X Cross References
| Brand | Part Number |
|---|---|
| 1300 | |
| N/A | 3559568 |
