(888) 312-8812 Login SignupBENDIX NT3030STD-56TC Spring Brake (S-Cam)
Tap to view 5 more
$10599
7 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
BENDIX NT3030STD-56TC Part Description
BENDIX NT3030STD-56TC Specifications
Product Attributes
| Brand | EnduraSure |
| Cautionary Note(s) | Do not disassemble while park side is caged under pressure |
| Chamber Style | Double Diaphragm |
| Chamber Type / Size | T30/30 |
| Clamp Angle | 0Adeg |
| Clevis / Yoke Arm Bushing Pin Diameter | A~ .50 IN (A~ 12.7 MM) |
| Clevis / Yoke Arm Link Pin Diameter | Not applicable to this part |
| Clevis / Yoke Pin Spacing | Not applicable to this part |
| Clevis / Yoke Style | Threaded (Standard) |
| Market Indicator | Aftermarket New |
| Maximum Operating Temperature | 175 AdegF (79 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting Stud Length | 1.50 IN (38.1 MM) |
| Parking Port (12) | 3/8-18 NPTF |
| Port Angle | 0Adeg |
| Push Rod Length (to Yoke Pin Center when Applicable) [IN] | 5.62 in |
| Push Rod Thread / Style | 5/8-18 UNF-2A |
| Service Chamber Joint Type | Double Clamp Band |
| Service Port (11) | 3/8-18 NPTF |
| Stroke | 2.50 IN (63.5 MM) |
| Stud Spacing | 4.75 IN (120.7 MM) |
| Stud Thread Size | 5/8-11 UNC-2A |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 04068078154724 |
| VMRS Code | 013004027 |
BENDIX NT3030STD-56TC Cross References
| Brand | Part Number |
|---|---|
| HALDEX | GC3030 |
| N/A | 800921 |
