BENDIX part description

Product Description

Spring Brake Valve

Features & Benefits

  • A highly reliable reservoir-mounted trailer valve that meets OE standards
  • Designed to control up to four spring brake actuators during parking or emergency applications
  • Automatically applies trailer spring brakes and protects trailer reservoir air pressure whenever there's a breakaway or trailer supply line failure
  • Applies and releases the trailer spring brakes repeatedly with a failed trailer reservoir(s)
  • Has optional anti-compounding feature to prevent an overriding service brake signal when the trailer supply line is at atmospheric pressure
  • Prevents service system charging when the parking brake circuit fails
  • Bendix SR-5 valves have one 1/2" or 3/4" NPT reservoir mounting port, one 1/4"-18 supply port, one 1/4"-18 service port, four 3/8"-18 delivery ports, two 1/4"-18 service reservoir ports, and a diaphragm-protected exhaust port
  • Made of premium-quality materials to withstand harsh operating conditions and last longer than the competition
  • All Bendix valves help save on maintenance and repair costs and reduce downtime

Courtesy of Bendix – All rights reserved

Bendix SR-5 Air Brake Spring Brake Modulating Valve

The Bendix SR-5 air brake spring brake modulating valve is the ideal replacement valve for your repair and maintenance project. Bendix engineers and tests this product using state-of-the-art technology to ensure the highest quality, maximum performance, and reliability.

Product Attributes

Series SR-5™

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (HTS) 8481200070
UPC 07894294751600
VMRS Code 013010104
