BENDIX 284726N Control Valve

★★★★★ (0)
Bendix 284726N Air Brake Control Valve Control Valve
BENDIX
Tap to view 7 more
Bendix 284726N Air Brake Control Valve Control Valve

MSRP: $130.31

$92.99

Save $37.32

Limited availability at this price!

In Stock

Get as soon as Friday, Oct 2
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

BENDIX 284726N Part Description

Manufacturer

BENDIX

Product Description

Control Valve

Features & Benefits

  • Valve seat closes fully against the internal poppet
  • Actuates cleanly and consistently without sticking at the seat
  • Poppet configuration matches the lines already connected to it
  • Mounts using the same bracket as the original valve

Bendix Air Brake Control Valve

Restore steady control over a secondary air circuit with the Bendix Air Brake Control Valve, replacing one that's begun sticking or leaking at the seat. A worn seat lets air bleed past even when the valve should be fully closed, which can drain a circuit slowly enough to go unnoticed until the system needs it. The Bendix 284726N uses the same port configuration and seat design as the valve it replaces, so connected lines reconnect without modification. A new control valve keeps the circuit it serves holding pressure the way the system was designed to.

BENDIX 284726N Specifications

Product Attributes

Automatic Release Pressure 40 PSI
Button Color Yellow (Black Band)
Button Shape Diamond
Button Text Pull to Apply | Parking Brake | Push to Release
Button(s) Included Yes
Control (Pilot / AUX) Port Not applicable to this part
Delivery Port 1 1/8-27 NPT
Delivery Port 2 1/8-27 NPT
Dial Included No
Exhaust Port 1/8-27 NPT
Market Indicator Aftermarket New
Maximum Operating Temperature 200 AdegF (93 AdegC)
Minimum Operating Temperature -40 AdegF (-40 AdegC)
Mounting 7/8-20 UNEF-2A
Mounting Nut Included Yes
Pilot Trip Pressure Not applicable to this part
Plunger / Button Height 1.59 IN
Plunger Diameter A~ .374 IN
Rubber Boot Included No
Supply Port 1/8-27 NPT
Trailer Override Pressure Not applicable to this part
VMRS Code 2 013-010-017
VMRS Code 3 013-010-049
VMRS Description 2 Parking Valve - Hand Brake, Air
VMRS Description 3 Parking Valve - Tractor

Additional Information

Country of Origin (Primary) MX
UPC 04068078321775
VMRS Code 013010014

BENDIX 284726N Cross References

BrandPart Number
BEN284726N, BW284726N
N/A239357N
NABI416.00.3804.778
WABCORKN20021
