(888) 312-8812 Login SignupRAYBESTOS 980727 Raybestos Specialty - Truck Brake Rotor
$9099
Limited availability at this price!
1 Day Lead Time
Get as soon as Friday, Oct 2
RAYBESTOS 980727 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2016-2009 Toyota Venza Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring:Optimal coolingReduced fadeLess noiseIncreased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 980727 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.441 IN |
| Center Hole Diameter | 62 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.35 IN |
| Discard Thickness | 8.9 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.566 IN |
| Mounting Bolt Hole Diameter | 14.4 MM |
| Nominal Thickness | 0.39 IN |
| Nominal Thickness | 9.9 MM |
| Outside Diameter | 11.732 IN |
| Outside Diameter | 298 MM |
| Overall Height | 2.748 IN |
| Overall Height | 69.8 MM |
| Salability Restrictions | No |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352807453 |
RAYBESTOS 980727 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH270084, YH270084C, YH270084P |
| AUTOPARTSOURCE | 479785 |
| AUTOXTRA | AX900760 |
| AUTOZONE | 71916DG, 71916 |
| Autoxtra | AX900760P |
| BENDIX | PRT5913 |
| BOSCH | 50011505 |
| BRAKEBEST | 50011505, 980727, 980727FZN, 980727R, 980727RGS |
| Brembo | 08.N430.11 |
| CENTRIC | 120.44169, 120.44169CRY, 121.44169, 126.44169SL, 126.44169SR, 127.44169L, 127.44169R, 320.44169 |
| Centric Parts | 120.44169, 120.44169CRY, 121.44169, 126.44169SL, 126.44169SR, 127.44169L, 127.44169R, 320.44169 |
| DURA CORP | BR31532, BR900760 |
| DuraGo | 900760, BR900760 |
| MAGMA PRODUCTS | PSR565185 |
| MONROE BRAKES | BD180363 |
| NEOTEK | 1063056GF |
| NEWTEK AUTOMOTIVE | 31532 |
| Newtek Automotive USA | 31532 |
| Omnicraft | QBRR75 |
| POWERSTOP | JBR1391EVC |
| PROMAX | 14-31532, 20-31532 |
| PRONTO | BR900760 |
| Qualis | 44645 |
| TOYOTA | 424310T010 |
| TopNotch | TN980727GEO |
| UAP | R44169 |
| WAGNER BRAKE | BD180363E |
| WINHERE | 661856 |
| WORLDPAC | 1407-270084, 1427-523968 |
| Wagner Brake | BD180363 |
RAYBESTOS 980727 Fits Vehicles
- Toyota Venza (2009-2016)
