(888) 312-8812 Login SignupRAYBESTOS 980693 Raybestos Specialty - Street Performance Brake Rotor
$5899
Limited availability at this price!
1 Day Lead Time
Get it by Friday, Sep 11
RAYBESTOS 980693 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2015-2008 Audi TT Quattro Rear, 2008 Audi TT Rear
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980693 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Center Hole Diameter | 2.596 IN |
| Center Hole Diameter | 65.95 MM |
| Construction | Full Cast |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.126 IN |
| Inside Diameter | 181 MM |
| Misc. Holes | 1 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.469 IN |
| Nominal Thickness | 11.9 MM |
| Outside Diameter | 11.256 IN |
| Outside Diameter | 285.9 MM |
| Overall Height | 2.291 IN |
| Overall Height | 58.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352822821 |
RAYBESTOS 980693 Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH200848, YH200848C, YH200848P, YH200943 |
| ATE BRAKE PRODUCTS | SP12175, 412175 |
| AUDI | 8J0615601 |
| AUTOZONE | 45457, 45457DG |
| BENDIX | PRT6014 |
| BOSCH | 14011487 |
| BRAKEBEST | 14011487, 980693, 980693R, 980693RGS |
| BREMBO | 08.9769.11 |
| Brembo | 08.9769.1X, 08.9769.1S |
| CENTRIC | 120.33119, 121.33119, 125.33119, 126.33119SL, 126.33119SR, 127.33119L, 127.33119R, 128.33119L, 128.33119R |
| Centric Parts | 121.33119, 125.33119, 126.33119SL, 126.33119SR, 127.33119L, 127.33119R, 128.33119L, 128.33119R, 120.33119 |
| DURA CORP | BR34402, BR900816 |
| DuraGo | 900816, BR900816 |
| Dynamic Friction Company | 604-73053 |
| NAPA BRAKES | SDK6640 |
| NEWTEK AUTOMOTIVE | 34402 |
| Newtek Automotive USA | 34402 |
| PROMAX | 14-34402 |
| PRONTO | BR900814 |
| Qualis | 45457 |
| TRW | 4784 |
| VAICO | V1040087 |
| WAGNER BRAKE | BD180101 |
| WINHERE | 661769 |
RAYBESTOS 980693 Fits Vehicles
- Audi TT Quattro (2008-2015)
- Audi TT (2008-2014)
