(888) 312-8812 Login SignupMONROE MA829 Max-Air Air Réglable Suspension pneumatique – Amortisseur Un paquet de 2
Tap to view 3 more
$20249
Limited availability at this price!
In Stock
Get it by Friday, Jul 17
MONROE MA829 Part Description
Manufacturer
Features & Benefits
- MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
- EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
- EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
- BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
MONROE MA829 Specifications
Product Attributes
| Compressed Length | 14.375 IN |
| Compressed Length | 365.1 MM |
| Extended Length | 631.8 MM |
| Extended Length | 24.875 in |
| Travel Length | 10.5 in |
| Travel Length | 266.7 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.1/2" Sleeve OAL |
| Lower Mount Code | LS38 |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Parts Pack(s) | P01136 |
| Part Description | Air Shock Absorber |
| Boot Included | Yes |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Grade Type | Premium |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708801910 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801300 |
| UPC | 00048598047953 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE MA829 Cross References
| Brand | Part Number |
|---|---|
| MA829MM, JK4Z6154251BA | |
| Ford | 1L3Z18124AC, 1L3Z18124BA, 1L3Z18125AA, 2L3Z18124AA, 2L3Z18124BA, 2L3Z18124BB, 2L3Z18124CA, 2L3Z18124DA, 2L3Z18124EA, 2L3Z18124MA, 2L3Z18125AA, 2L3Z18125BA, 2L3Z18125BB, 2L3Z18125CA, 2L3Z18125EA, 2L3Z18125FA, 2L3Z18125GA, 2L3Z18125HA, 2L3Z18125KA, 3L3Z18124AA, 3L3Z18125AA, 3U2Z18124BB, 3U2Z18124BM, 3U2Z18124DAA, 3U2Z18124QAA, 3U2Z18124RAA, 5U2Z18V125AD, F65Z18124EB, F65Z18124FB, F65Z18124GA, F65Z18124HB, F65Z18124KA, F65Z18124KB, F65Z18125AB, F65Z18125BB, F65Z18125CB, F65Z18125DC, F75Z18125AG, F75Z18125AH, F75Z18125DC, F75Z18125HA, F75Z18125HC, F75Z18125PC, F85Z18124LA, XL3Z18124AA, XL3Z18124CA, XL3Z18125CA, YL3Z18124AA, YL3Z18124BA, YL3Z18124CA, YL3Z18124DA, YL3Z18125AA, YL3Z18125BA, YL3Z18125CA, YL3Z18125DA, YL3Z18125EA |
| GABRIEL | 49237 |
| NAPA Shocks | MA829 |
MONROE MA829 Fits Vehicles
- Ford F-100 Ranger (1997-2001)
- Ford F-150 Heritage (2004)
- Ford F-150 (1997-2003)
