RAYBESTOS 782869 Raybestos Specialty - Truck Brake Rotor

782869 by RAYBESTOS - Raybestos Specialty - Truck Brake Rotor
RAYBESTOS
Tap to view 5 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

RAYBESTOS 782869 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Truck Brake Rotor

Features & Benefits

  • OE Fit, Form, and Function
  • Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
  • Cooling Vanes
  • We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
  • Coating
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
  • SAE Standard for Tensile Strength
  • Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
  • Turned Finish
  • A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
Raybestos Specialty - Truck Brake Rotor

RAYBESTOS 782869 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.835 IN
Conventional Or Drum-In-Hat Type Rotor Conventional
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 0.472 IN
Inside Diameter 8.465 IN
Material Cast Iron
Mounting Bolt Hole Circle Diameter 5 IN
Mounting Bolt Hole Diameter 0.669 IN
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.551 IN
Outside Diameter 12.791 IN
Overall Height 1.614 IN
Solid Or Vented Type Rotor Solid
Bearings Included No
Construction Full Cast
Grade Type Regular
Center Hole Diameter 72 MM
Discard Thickness 12 MM
Inside Diameter 215 MM
Mounting Bolt Hole Circle Diameter 127 MM
Mounting Bolt Hole Diameter 17 MM
Nominal Thickness 14 MM
Outside Diameter 324.9 MM
Overall Height 41 MM

Additional Information

Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030

RAYBESTOS 782869 Cross References

BrandPart Number
AutoZone72242DL
BrakeBest782869RGS
Centric Parts120.58027, 121.58027
Chrysler68376814AA
Dura CorpBR901966
DuraGoBR901966, BR901966-01
Dynamic Friction Company604-42047
Jeep68376814AA, 68376814AB
Winhere6612610

RAYBESTOS 782869 Fits Vehicles

  • Jeep Grand Cherokee (2022-2024)
  • Jeep Grand Cherokee L (2022-2024)

RAYBESTOS 782869 Customer Reviews

No reviews yet

Be the first to review this product!

RAYBESTOS 782869 Manufacturer Information

For ultimate braking power, trust only the best in brakes—Raybestos®. This industry giant has been revolutionizing people’s perception of brakes and braking performance for over 100 years now. Raybestos’ unwavering commitment to providing the automotive aftermarket with top-caliber brake parts makes it the most sought-after brand of brake solutions for commercial vehicles, motorhomes, buses, performance vehicles, and other automotive applications. With its cutting-edge technology and outstanding research and product development capabilities, this brand produces a comprehensive line of brake products that adhere to OE specifications and meet stringent industry standards. From pads to rotors, calipers to cylinders, Raybestos ensures dependable brake parts that deliver the best-in-class performance and unparalleled driving safety that customers expect from an industry leader.
