Raybestos 8581 - Raybestos Specialty - Truck Coated Brake Rotor
$28449
5 day lead time
limited availability at this price!
RAYBESTOS part description
Product Description
Raybestos Specialty - Truck Coated Brake Rotor
Product Attributes
ABS Tone Ring Included | Yes |
Center Hole Diameter | 4.157 IN |
9565 | Conventional |
9540 | Non-Directional |
Discard Thickness | 1.457 IN |
Inside Diameter | 8.74 IN |
Mounting Bolt Hole Circle Diameter | 7.717 IN |
Mounting Bolt Hole Quantity | 8 |
Nominal Thickness | 1.772 IN |
Outside Diameter | 14.618 IN |
Overall Height | 5.461 IN |
Solid Or Vented Type Rotor | Vented |
Surface Type | Smooth |
Bearings Included | No |
Construction | Full Cast |
Grade Type | Regular |
Bolt Thread Pitch | 0.079 IN |
Harmonize Code | 8708.30.5030 |
Salability Restrictions | No |
UNSPSC Code | 25171715 |
Notes | Wabco Pan 19 |
Hat Finish | Coated |
Rust Resistant Coating | Yes |
Disc Finish | Coated |
Center Hole Diameter | 105.6 MM |
Discard Thickness | 37 MM |
Inside Diameter | 222 MM |
Mounting Bolt Hole Circle Diameter | 196 MM |
Nominal Thickness | 45 MM |
Outside Diameter | 371.3 MM |
Overall Height | 138.7 MM |
Bolt Thread Pitch | 2 MM |
Additional Information
Country of Origin (Primary) | CN |
UPC | 00887213396829 |
Part Interchanges
For ultimate braking power, trust only the best in brakes—Raybestos®. This industry giant has been revolutionizing people’s perception of brakes and braking performance for over 100 years now. Raybestos’ unwavering commitment to providing the automotive aftermarket with top-caliber brake parts makes it the most sought-after brand of brake solutions for commercial vehicles, motorhomes, buses, performance vehicles, and other automotive applications. With its cutting-edge technology and outstanding research and product development capabilities, this brand produces a comprehensive line of brake products that adhere to OE specifications and meet stringent industry standards. From pads to rotors, calipers to cylinders, Raybestos ensures dependable brake parts that deliver the best-in-class performance and unparalleled driving safety that customers expect from an industry leader.
