RAYBESTOS 56629R2 Part Description
Manufacturer
Product Description
Raybestos R-Line+ Brake Rotor
Features & Benefits
- Painted Hat and Edges
- Top-Notch Surface Finish
- Superior surface finish for consistent braking.
- OE Vane Design
- OE vane design and plate thickness for heat capacity and strength.
- Advanced Metallurgy
- Advanced metallurgy for structural strength and heat transfer.
- Low Initial Lateral Run-out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free braking.
- Precision Balance
- Precision balance for vibration free performance.
Raybestos R-Line+ Brake Rotor
RAYBESTOS 56629R2 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.78 IN |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.354 IN |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.646 IN |
| Mounting Bolt Hole Diameter | 0.636 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.435 IN |
| Outside Diameter | 10.94 IN |
| Overall Height | 1.98 IN |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Center Hole Diameter | 70.6 MM |
| Discard Thickness | 9 MM |
| Mounting Bolt Hole Circle Diameter | 118 MM |
| Mounting Bolt Hole Diameter | 16.15 MM |
| Nominal Thickness | 11.05 MM |
| Outside Diameter | 277.9 MM |
| Overall Height | 50.3 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213445626 |
RAYBESTOS 56629R2 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 177-831 |
| API | 1407-25660 |
| Advance Auto Parts | 145155, YH145155, YH145155C, YH145155P |
| American Remanufactured | 789-36058, 89-36058 |
| AutoZone | 55039, 55039B, 55039DG, 55039DL, DL55039 |
| Autopartsource | 593030 |
| Autospecialty | AR8258, AR8258E |
| Autoxtra | 1255039, 125506, 8056629, AX55039 |
| Bendix | 145155 |
| Bosch | RBR55039 |
| Brake Headquarters | BR55596 |
| BrakeBest | 25010535, 56629, 56629FZN, 56629R, 56629RGS, 81-125506, BD125506 |
| Brembo | 08.8463.10, 08.8463.85, 27190, 08.8463.11 |
| California Drum & Rotor | 125506 |
| Casting Numbers | 18021353, 325279, 5162, 550391 |
| Centric Parts | 120.62058, 120.62058CRY, 121.62058, 125.62058, 125.62058CRY, 126.62058CSL, 126.62058CSR, 126.62058SL, 126.62058SR, 127.62058CL, 127.62058CR, 127.62058L, 127.62058R, 128.62058CL, 128.62058CR, 128.62058L, 128.62058R, 227.62058L, 227.62058R, 320.62058, 321.62058 |
| Command Automotive | 107235 |
| Continental-ContiTech | CW11133 |
| Delphi | RB499 |
| Dura Corp | BR55039, BR5503902 |
| DuraGo | BR55039, BR5503902 |
| Eurorotor | 55114 |
| GREN | 684901 |
| General Motors | 18021354, 18060232, 19303830 |
| Guardian | 52-125506 |
| Midas | BR2018 |
| Mighty Distributing System | 55039 |
| Monroe Brakes | BD125506 |
| Newtek Automotive USA | 55039 |
| Omnicraft | QBRR134 |
| Parts Master | P125506 |
| Performance Friction | 278.050.01 |
| PowerStop | AR8258EVC |
| Promax | 14-55039, 20-55039 |
| Qualis | 55039 |
| Quality Brand | 55039, Q4008 |
| Quinton Hazell | BDC4798 |
| Standard Rotors and Drums | 55039 |
| TopNotch | TN56629GEO |
| TruStar | 493030 |
| UAP | 2055039, 55039 |
| Ultra Brake | 55145 |
| Universal | 101706 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51188 |
| WABCO - Archived | PS125506 |
| WORLDPAC | 1407-25660 |
| Wagner Brake | BD125506, BD125506E |
| Winhere | 661186, YH1186 |
RAYBESTOS 56629R2 Fits Vehicles
- Chevrolet Impala (2000-2005)
- Oldsmobile Intrigue (1998-2002)
- Pontiac Grand Am (1999-2005)
- Pontiac Grand Prix (1997-2003)
- Buick Century (1997-2005)
- Oldsmobile Alero (1999-2004)
- Buick Regal (1997-2004)
- Pontiac Montana (1999-2001)
- Chevrolet Monte Carlo (2000-2005)
- Pontiac Trans Sport (1997-1999)
- Chevrolet Venture (1998-2005)
- Buick Riviera (1999)
