(888) 312-8812 Login SignupGATES 71029 MegaTech G5TB Oil-Air Return Hose
$69.35
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 71029 Part Description
Manufacturer
Product Description
MegaTech G5TB Oil-Air Return Hose
Features & Benefits
- For use with GL Couplings [G43 Series], GlobalSpiral Plus Couplings [G22 Series] and MegaCrimp Couplings [G25 Series]
- Temperature Range: Petroleum-based Fluids: -40 Deg. F to +300 Deg. F (-40 Deg. C to +149 Deg. C); Phosphate Esters Fluids as recommended by the fluid manufacturer but within a range of -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
GATES 71029 Specifications
Product Attributes
| Product Type | MegaTech G5TB Oil-Air Return Hose |
| Industrial Description | 32MEGATECH G5TBXCTN |
| Type | Fleet Application & Maintenance Hose |
| Hose Pressure Description | High Pressure |
| Maximum Working Pressure | 500 PS |
| Burst Pressure | 2000 PS |
| Temperature Rating | -40 Deg. F to +300 Deg. F (Petroleum-Base Fluid); -40 Deg. F to +212 Deg. F (Phosphate Ester Fluids) |
| Length | 100 FT |
| Dash Size | 32 |
| Inside Diameter | 2 IN |
| Outside Diameter | 2.53 IN |
| Bend Radius | 10.5 IN |
| Tube Description | Black, True-Bore |
| Hose Material | CPE - Type J |
| Reinforcement Material | Two Braids, High-Tensile Steel Wire |
| Cover Material | Textile Braid Impregnated w/ Synthetic Rubber |
| Cover Type | Oil & Mildew Resistant |
| Cover Color | Blue |
| Coupling Recommendation | GL, GlobalSpiral Plus |
| SAE Standard | N/A |
| EN Standard | N/A |
| ISO Standard | N/A |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00770075251767 |
| VMRS Code | 059032029 |
| UNSPSC | 40142000 |
GATES 71029 Cross References
| Brand | Part Number |
|---|---|
| NAPA | 71029 |
