ICON K53221 Part Description
Manufacturer
Product Description
05-23 TACOMA 0-2" STAGE 2 EXP SUSPENSION SYSTEM
Features & Benefits
- Vehicle specific design for 2005-2023 Toyota Tacoma
- 2.5 EXP Series front shocks with internal reservoirs utilize factory coil and coil hardware
- Adjustable front ride heights from 0-2” of front lift over stock with the use of snap ring
- Included sway bar relocation brackets reduce ensure sway bar clearance from EXP coilovers
- Allows for full wheel travel without overstressing OE components
- Rear Add-a-Leaf softens spring rate for improved ride quality while providing 1.5” of rear lift
- 2.0 Aluminum Series rear shocks provide balanced tune with coilovers and increased performance
- All ICON shock absorbers are fully rebuildable and re-tunable
OEM Wheels & Tires Fitment: Yes
05-22 TACOMA 0-2' STAGE 2 EXP SUSPE
ICON K53221 Specifications
Product Attributes
| Aap_uda_12 | EA |
| Aap_uda_22 | 1 |
| Aap_uda_4 | 55 |
| Adjustable Damping | No |
| Bushings Included | Yes |
| California Prop 65 Warning | Yes |
| Grade Type | Performance |
| Maximum Lift Front | 2 IN |
| Maximum Lift Rear | 1.5 IN |
| Minimum Lift Front | 0 IN |
| Mounting Hardware Included | Yes |
| OEM Wheels & Tires Fitment | Yes |
| Rear Spring Rate Type | Linear |
| Recommended Aftermarket Tires | 33" x 11.50" (Minor fender trimming may be required) |
| Recommended Aftermarket Wheels | ICON Alloys - 20x9 with 5.00” Backspace / 0mm Offset |
| Shocks Included | Yes |
| Title | ICON 2005-2023 Toyota Tacoma, 0-2" Lift, Stage 2 EXP Suspension System |
Additional Information
| Warranty Special | 1 Year-Shock Absorbers; Limited Lifetime-Leaf Springs |
| Warranty Special UOM | TX |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| NAFTA Preference Criterion Code | C |
| UPC | 00840103421087 |
ICON K53221 Fits Vehicles
- Toyota Tacoma (2005-2023)
