DELPHI TC7053 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
Control Arm and Ball Joint Assembly
DELPHI TC7053 Specifications
Product Attributes
| Position(s) | Front Left Upper |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | Yes |
| Greaseable | No |
| Control Arm Maximum Width | 283.00 MM |
| Control Arm Maximum Width | 11.142 IN |
| Control Arm Color | Black |
| Ball Joint Stud Length | 31.50 MM |
| Ball Joint Stud Length | 1.240 IN |
| Control Arm Maximum Length | 359.00 MM |
| Control Arm Maximum Length | 14.134 IN |
| Mounting Hole Diameter | 12.10 MM |
| Mounting Hole Diameter | 0.476 IN |
| Distance Between Bushings | 282.50 MM |
| Distance Between Bushings | 11.122 IN |
| Bushing Inside Diameter | 12.10 MM |
| Bushing Length | 62.00 MM |
| Bushing Length | 2.441 IN |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Bushing Inside Diameter | 0.476 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| UPC | 00689604387924 |
| VMRS Code | 016001002 |
| UNSPSC | 25172013 |
DELPHI TC7053 Cross References
DELPHI TC7053 Fits Vehicles
- Mercedes-Benz S450 (2018)
- Mercedes-Benz Maybach S650 (2018)
- Mercedes-Benz Maybach S560 (2018)
- Mercedes-Benz S560 (2018)
- Mercedes-Benz Maybach S550 (2017)
- Mercedes-Benz S550e (2015-2017)
- Mercedes-Benz Maybach S600 (2016-2017)
- Mercedes-Benz S600 (2015-2017)
- Mercedes-Benz S550 (2014-2017)
