Need help? We're here!
(888) 312-8812 Login SignupRAYBESTOS 980230 Raybestos Specialty - Truck Brake Rotor
MSRP: $125.50
$9649
Save $29.01
Limited availability at this price!
In Stock
Get it by Friday, Jul 10
RAYBESTOS 980230 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2018-2008,2006-2003 Porsche Cayenne Rear, 2015-2007 Audi Q7 Rear, 2017-2004 Volkswagen Touareg Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 980230 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.347 IN |
| Center Hole Diameter | 85 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Mounting Bolt Hole Circle Diameter | 130 MM |
| Mounting Bolt Hole Diameter | 0.598 IN |
| Mounting Bolt Hole Diameter | 15.2 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.984 IN |
| Outside Diameter | 329.8 MM |
| Overall Height | 2.898 IN |
| Overall Height | 73.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | IT |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352358122 |
RAYBESTOS 980230 Cross References
| Brand | Part Number |
|---|---|
| 829352358122, 120.33078 | |
| ADVANCE AUTO PARTS | YH145758, YH145758C, YH145758P |
| ATE BRAKE PRODUCTS | SP28149, 428149 |
| AUTOXTRA | AX900478 |
| AUTOZONE | 45093, 45093DG, 45093DL |
| BENDIX | BPR5758, PRT5758 |
| BRAKEBEST | 980230, 980230FZN, 980230R |
| BREMBO | 09.A056.11 |
| BrakeBest | 980230RGS |
| Brembo | 09.C884.11, 09.C884.1S |
| CENTRIC | 120.33078, 121.33078, 125.33078, 125.33078CRY, 126.33078CSL, 126.33078CSR, 126.33078SL, 126.33078SR, 127.33078CL, 127.33078CR, 127.33078L, 127.33078R, 128.33078L, 128.33078R, 227.33078L, 227.33078R, 320.33078, 320.33078H, 321.33078 |
| Centric Parts | 120.33078, 121.33078, 125.33078, 125.33078CRY, 126.33078CSL, 126.33078CSR, 126.33078SL, 126.33078SR, 127.33078CL, 127.33078CR, 127.33078L, 127.33078R, 128.33078L, 128.33078R, 227.33078L, 227.33078R, 320.33078, 320.33078H, 321.33078 |
| DURA CORP | BR34287, BR900478 |
| DuraGo | 900478, BR900478 |
| Dynamic Friction Company | 604-74048 |
| MAGMA PRODUCTS | PSR585103 |
| NAPA BRAKES | SDK6399, TSR9208, TSR9245 |
| NEWTEK AUTOMOTIVE | 34287 |
| Newtek Automotive USA | 34287 |
| PAGID | 355109822 |
| PAGID Racing | 355109822 |
| PORSCHE | 95535240130, 95535240131 |
| POWERSTOP | EBR1013EVC |
| PROMAX | 14-34287 |
| PRONTO | BR900478 |
| Qualis | 45093 |
| TRW | 4487, DF4487S |
| TopNotch | TN980230GEO |
| UAP | 34287 |
| VAICO | V1080006 |
| VOLKSWAGEN | 7L6615601D, 7L6615601J, 7L8615601C |
| WABCO | PS126340 |
| WABCO - Archived | PS126340 |
| WAGNER | BD126340, BD126340E |
| WAGNER BRAKE | BD126340, BD180419 |
| WINHERE | 6620208 |
| WORLDPAC | 1407-77183, 1427-530190 |
| Wagner Brake | BD126340E |
RAYBESTOS 980230 Fits Vehicles
- Audi Q7 (2007-2015)
- Volkswagen Touareg (2004-2018)
- Porsche Cayenne (2003-2006, 2008-2018)
