(888) 312-8812 Login SignupRAYBESTOS 980742 Raybestos Specialty - Street Performance Brake Rotor
$12249
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Jul 20
RAYBESTOS 980742 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2008 BMW 535xi Front, 2010-2009 BMW 535i xDrive Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980742 Specifications
Product Attributes
| Center Hole Diameter | 3.109 IN |
| Center Hole Diameter | 78.95 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.118 IN |
| Discard Thickness | 28.4 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 7.464 IN |
| Inside Diameter | 189.6 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.578 IN |
| Mounting Bolt Hole Diameter | 14.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30 MM |
| Outside Diameter | 12.751 IN |
| Outside Diameter | 323.9 MM |
| Overall Height | 3.037 IN |
| Overall Height | 77.15 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352744239 |
RAYBESTOS 980742 Cross References
| Brand | Part Number |
|---|---|
| ECO3035H, 829352744239 | |
| ADVANCE AUTO PARTS | YH200349 |
| AUTOZONE | 45407 |
| BENDIX | PRT6031 |
| BMW | 34116767269 |
| BOSCH | 15010132 |
| BRAKEBEST | 15010132, 980742, 980742RGS |
| BREMBO | 09.9172.1X, 09.9172.11 |
| CENTRIC | 120.34071, 121.34071, 125.34071, 125.34071CRY, 126.34071CSL, 126.34071CSR, 126.34071SL, 126.34071SR, 127.34071CL, 127.34071CR, 127.34071L, 127.34071R, 128.34071L, 128.34071R, 128.34071CL, 128.34071CR, 320.34071, 320.34071H, 125.34070 |
| Centric Parts | 120.34071, 121.34071, 125.34071, 125.34071CRY, 126.34071CSL, 126.34071CSR, 126.34071SL, 126.34071SR, 127.34071CL, 127.34071CR, 127.34071L, 127.34071R, 128.34071CL, 128.34071CR, 128.34071L, 128.34071R, 320.34071, 320.34071H |
| DURA CORP | BR34417, BR900730 |
| DuraGo | BR900730 |
| MAGMA PRODUCTS | PSR123084 |
| NEOTEK | 1066503GF |
| NEWTEK AUTOMOTIVE | 34417 |
| Newtek Automotive USA | 34417 |
| UAP | R34104 |
| VAICO | V2080051 |
| WAGNER BRAKE | BD180291 |
| Wagner Brake | BD180291E |
| Winhere | 6621566 |
RAYBESTOS 980742 Fits Vehicles
- BMW 535i xDrive (2009-2010)
- BMW 535xi (2008)
