RAYBESTOS 980343 Raybestos Specialty - Street Performance Brake Rotor

★★★★★ (0)

$136.99

Limited availability at this price!

In Stock

Get as soon as Monday, Nov 30
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

RAYBESTOS 980343 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2012-2005 Acura RL Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes:Black fusion coating on the rotor hatGrey Fusion 4.0® coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 980343 Specifications

Product Attributes

ABS Tone Ring IncludedNo
Center Hole Diameter2.76 IN
Center Hole Diameter70.1 MM
Conventional Or Drum-In-Hat Type RotorConventional
Discard Thickness1.024 IN
Discard Thickness26 MM
Harmonize Code8708.30.5030
Mounting Bolt Hole Circle Diameter4.724 IN
Mounting Bolt Hole Circle Diameter120 MM
Mounting Bolt Hole Diameter0.58 IN
Mounting Bolt Hole Diameter14.75 MM
Mounting Bolt Hole Quantity5
Nominal Thickness1.102 IN
Nominal Thickness28 MM
Outside Diameter12.591 IN
Outside Diameter319.8 MM
Overall Height1.974 IN
Overall Height50.15 MM
Salability RestrictionsNo
Solid Or Vented Type RotorVented
Stud/Lug Hole Quantity5
UNSPSC Code25171715

Additional Information

Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708309990
Harmonized Tariff Code (HTS)8708305030
UPC00829352601204

RAYBESTOS 980343 Cross References

BrandPart Number
BRC186RM, 829352601204
ADVANCE AUTO PARTS200365, YH200365, YH200365C, YH200365P
AUTOXTRAAX900836
AUTOZONE50101, 50101DG
BENDIXPRT5951
BOSCH26011448
BRAKEBEST25011448, 26011448, 980343, 980343FZN, 980343R, 980343RGS
CENTRIC120.40066, 121.40066, 125.40066, 125.40066CRY, 126.40066CSL, 126.40066CSR, 126.40066SL, 126.40066SR, 127.40066CL, 127.40066CR, 127.40066L, 127.40066R, 128.40066CL, 128.40066CR, 128.40066L, 128.40066R, 320.40066, 320.40066C, 320.40066H
Centric Parts120.40066, 121.40066, 125.40066, 125.40066CRY, 126.40066CSL, 126.40066CSR, 126.40066SL, 126.40066SR, 127.40066CL, 127.40066CR, 127.40066L, 127.40066R, 128.40066CL, 128.40066CR, 128.40066L, 128.40066R, 320.40066C, 320.40066, 320.40066H
DURA CORPBR31394, BR900836
DuraGo900836, BR31394, BR900836
HONDA45251SJA903, 45251SJA900, 45251SJA902
NEOTEK106260GF
NEWTEK AUTOMOTIVE31394
Newtek Automotive USA31394
POWERSTOPJBR1141EVC
PROMAX14-31394
PRONTOBR900836
Qualis44672
UAP31394
WABCOPS126295
WABCO - ArchivedPS126295
WAGNER44061, BD126295E
WAGNER BRAKEBD126295
WINHERE6620663
WORLDPAC1407-77128
Wagner BrakeBD126295E

RAYBESTOS 980343 Fits Vehicles

  • Acura RL (2005-2012)
