(888) 312-8812 Login SignupRAYBESTOS 96922 Raybestos Specialty - Truck Brake Rotor
$9249
Limited availability at this price!
In Stock
Get it by Friday, Jan 9
RAYBESTOS 96922 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2006-2002 Suzuki XL-7 Front, 2005-1999 Suzuki Grand Vitara Front
RAYBESTOS 96922 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.27 IN |
| Center Hole Diameter | 108.45 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.5 IN |
| Mounting Bolt Hole Diameter | 12.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22 MM |
| Outside Diameter | 12.195 IN |
| Outside Diameter | 309.75 MM |
| Overall Height | 1.14 IN |
| Overall Height | 28.95 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00747730721019 |
RAYBESTOS 96922 Part Interchanges
| Brand | Part Number |
|---|---|
| Suzuki | 5521165D11, 5521165D12, 5521165D13 |
| Beck/Arnley | 083-2869 |
| Brembo | 09.9089.85, 25648 |
| Mighty Distributing System | 31289 |
| Wagner Brake | BD125736, BD125736E |
| Bendix | 145296 |
| Guardian | 52-125736 |
| Quality Brand | 31289, Q609 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51403 |
| PowerStop | JBR904EVC |
| BrakeBest | 49011211, 81-125736, 96922, 96922FZN, 96922R, 96922RGS, BD125736 |
| WABCO - Archived | PS125736 |
| AutoZone | 31276, 31276DG, 31289, DL31289 |
| Monroe Brakes | BD125736 |
| Advance Auto Parts | 145296, N1000322262APO, YH145296, YH145296C, YH145296P |
| Autoxtra | 125736, 8096922, AX31289 |
| Casting Numbers | 211244-C, 325563 |
| Dura Corp | BR31289 |
| Standard Rotors and Drums | 31289 |
| GREN | 81802 |
| Qualis | 31289, 31276 |
| TruStar | 478090 |
| Winhere | 662673, YH2673 |
| Newtek Automotive USA | 31289 |
| Pep Boys | 31289G |
| TRW | 4156 |
| Promax | 14-31289 |
| UAP | 31289 |
| NAPA BRAKES | SDK6430 |
| Ultra Brake | SZ-813 |
| Centric Parts | 120.48008, 121.48008, 125.48008, 126.48008SL, 126.48008SR, 127.48008L, 127.48008R, 128.48008CL, 128.48008CR, 128.48008L, 128.48008R, 320.48008 |
| DuraGo | BR31289 |
RAYBESTOS 96922 Fits Vehicles
- Suzuki XL-7 (2002-2006)
- Suzuki Grand Vitara (1999-2005)
RAYBESTOS 96922 Cross References
We have 50 alternatives for the 96922 by RAYBESTOS:
- 74821113
- 747730721019
- BENDIX 145296
- WABCO PS125736
- ADVANCE AUTO PARTS 145296
- ADVANCE AUTO PARTS N1000322262APO
- ADVANCE AUTO PARTS YH145296
- ADVANCE AUTO PARTS YH145296C
- ADVANCE AUTO PARTS YH145296P
- AUTOXTRA 125736
- AUTOXTRA 8096922
- AUTOXTRA AX31289
- AUTOZONE 31276
- AUTOZONE 31276DG
- AUTOZONE 31289
- AUTOZONE DL31289
- BECK/ARNLEY 083-2869
- BRAKEBEST 49011211
- BRAKEBEST 81-125736
- BRAKEBEST 96922
- BRAKEBEST 96922FZN
- BRAKEBEST 96922R
- BRAKEBEST 96922RGS
- BRAKEBEST BD125736
- BREMBO 09.9089.85
- BREMBO 25648
- DURA CORP BR31289
- GREN 81802
- GUARDIAN 52-125736
- MIGHTY DISTRIBUTING SYSTEM 31289
- MONROE BRAKES BD125736
- NAPA BRAKES SDK6430
- NEWTEK AUTOMOTIVE 31289
- PEP BOYS 31289G
- POWERSTOP JBR904EVC
- PROMAX 14-31289
- QUALIS 31289
- QUALITY BRAND 31289
- QUALITY BRAND Q609
- STANDARD ROTORS AND DRUMS 31289
- SUZUKI 5521165D11
- SUZUKI 5521165D12
- SUZUKI 5521165D13
- TRUSTAR 478090
- TRW 4156
- UAP 31289
- VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING X51403
- WAGNER BRAKE BD125736
- WINHERE 662673
- WINHERE YH2673
