RAYBESTOS 56702 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2013-1997 Chevrolet Corvette Rear Left, 2009-2004 Cadillac XLR Rear Left
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 56702 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.782 IN |
| Center Hole Diameter | 70.65 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.964 IN |
| Discard Thickness | 24.5 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.75 IN |
| Mounting Bolt Hole Circle Diameter | 120.65 MM |
| Mounting Bolt Hole Diameter | 0.526 IN |
| Mounting Bolt Hole Diameter | 13.35 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.025 IN |
| Nominal Thickness | 26.05 MM |
| Outside Diameter | 12 IN |
| Outside Diameter | 304.8 MM |
| Overall Height | 1.905 IN |
| Overall Height | 48.4 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730616643 |
RAYBESTOS 56702 Cross References
| Brand | Part Number |
|---|---|
| ACDELCO | 177-837, 177-854 |
| ADVANCE AUTO PARTS | 145170, YH145170 |
| AMERICAN REMANUFACTURED | 89-36061 |
| AUTOSPECIALTY | AR8261, AR8261E |
| AUTOXTRA | 125541 |
| AutoZone | 55045 |
| BENDIX | 145170 |
| BOSCH | 25010647 |
| BRAKEBEST | 25010647, 56702RGS, 56702, 56702R, BD125541 |
| BREMBO | 09.8512.85, 27195 |
| CALIFORNIA DRUM & ROTOR | 125541, 125557 |
| CENTRIC | 120.62061, 120.62061CRY, 121.62061, 125.62061, 125.62061CRY, 126.62061CSL, 126.62061SL, 127.62061CL, 127.62061L, 128.62061CL, 128.62061L, 227.62061L, 320.62061F |
| CONTINENTAL-CONTITECH | CW26755 |
| Casting Numbers | 10445859, 211129-C, 325459 |
| Centric Parts | 120.62061, 120.62061CRY, 121.62061, 125.62061, 125.62061CRY, 126.62061CSL, 126.62061SL, 127.62061CL, 127.62061L, 128.62061CL, 128.62061L, 227.62061L, 320.62061F |
| DURA CORP | BR55045 |
| DuraGo | 900500, 900772, BR55045, BR900772 |
| EUROROTOR | 55211L |
| GM | 10262997, 10406649, 10445859 |
| GREN | 672302 |
| General Motors | 10262997, 10406649, 10445859 |
| MAGMA PRODUCTS | PSR223064 |
| MIGHTY DISTRIBUTING SYSTEM | 55045 |
| MONROE BRAKES | BD125541 |
| NEWTEK AUTOMOTIVE | 55045 |
| Newtek Automotive USA | 55045 |
| PROMAX | 14-55045 |
| QUALIS | 55045 |
| QUALITY BRAND | 55045, Q4106 |
| Qualis | 41132 |
| STANDARD ROTORS AND DRUMS | 55045 |
| THE UNIVERSAL GROUP | 101934 |
| TRUSTAR | 493035 |
| UAP | 55045 |
| Universal | 101934 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51308 |
| WABCO | PS125541, PS125557 |
| WABCO - Archived | PS125541, PS125557 |
| WAGNER | BD125541 |
| WAGNER BRAKE | BD125541 |
| WINHERE | 4420001 |
RAYBESTOS 56702 Fits Vehicles
- Chevrolet Corvette (1997-2013)
- Cadillac XLR (2004-2009)
