(888) 312-8812 Login SignupRAYBESTOS 980262R Raybestos R-Line Brake Rotor
$5549
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Jul 16
RAYBESTOS 980262R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2003-2000 Volkswagen EuroVan Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980262R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.683 IN |
| Center Hole Diameter | 68.15 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.453 IN |
| Discard Thickness | 11.5 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 0.645 IN |
| Mounting Bolt Hole Diameter | 16.4 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.531 IN |
| Nominal Thickness | 13.5 MM |
| Outside Diameter | 11.575 IN |
| Outside Diameter | 294 MM |
| Overall Height | 1.614 IN |
| Overall Height | 41 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352467688 |
RAYBESTOS 980262R Cross References
| Brand | Part Number |
|---|---|
| ASH22342, 829352467688 | |
| AUTOZONE | 34244, 34244DG |
| BENDIX | 145530 |
| BRAKEBEST | 980262, 980262R, 980262RGS |
| BREMBO | 25713 |
| Brembo | 08.9176.11 |
| CENTRIC | 120.33076, 121.33076, 125.33076, 125.33076CRY, 126.33076SL, 126.33076SR, 127.33076CL, 127.33076CR, 127.33076L, 127.33076R, 320.33076H |
| CONTINENTAL-CONTITECH | CW13194 |
| Casting Numbers | 326170 |
| Centric Parts | 120.33076, 121.33076, 125.33076, 125.33076CRY, 126.33076SL, 126.33076SR, 127.33076CL, 127.33076CR, 127.33076L, 127.33076R, 320.33076H |
| DURA CORP | BR34244 |
| DuraGo | BR34244 |
| MAGMA PRODUCTS | PMR585100 |
| MIGHTY DISTRIBUTING SYSTEM | 34244 |
| NEWTEK AUTOMOTIVE | 34244 |
| Newtek Automotive USA | 34244 |
| PILENGA | V875 |
| QUINTON HAZELL | BDC5216 |
| Qualis | 34244 |
| UAP | 34244 |
| VAICO | V1040080 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51570 |
| VOLKSWAGEN | 7D0615601C |
| WAGNER | BD126103 |
| WAGNER BRAKE | BD126103 |
RAYBESTOS 980262R Fits Vehicles
- Volkswagen Sharan (2002-2008)
- Volkswagen EuroVan (2000-2003)
