RAYBESTOS 56450R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1996-1994 Chevrolet Caprice Rear, 1996-1994 Chevrolet Impala Rear, 1994 Chevrolet Commercial Chassis Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 56450R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.067 IN |
| Center Hole Diameter | 77.9 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.724 IN |
| Discard Thickness | 18.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5 IN |
| Mounting Bolt Hole Circle Diameter | 127 MM |
| Mounting Bolt Hole Diameter | 0.5 IN |
| Mounting Bolt Hole Diameter | 12.7 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.785 IN |
| Nominal Thickness | 19.95 MM |
| Outside Diameter | 11.61 IN |
| Outside Diameter | 294.9 MM |
| Overall Height | 2.335 IN |
| Overall Height | 59.3 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352364222 |
RAYBESTOS 56450R Cross References
| Brand | Part Number |
|---|---|
| ACDELCO | 177-766 |
| ADVANCE AUTO PARTS | 145033, YH145033 |
| AMERICAN REMANUFACTURED | 789-36053, 89-36053 |
| AUTOPART INTERNATIONAL | 25087 |
| AUTOSPECIALTY | AR8253, AR8253E |
| AUTOZONE | 55017 |
| Autoxtra | AX55017 |
| BENDIX | 145033, 145036 |
| BRAKE HEADQUARTERS | BR55675 |
| BRAKEBEST | 25010622, 56450, 56450R, 56450RGS, 81-125417, BD125417 |
| BREMBO | 09.8827.85, 27216 |
| CALIFORNIA DRUM & ROTOR | 125417 |
| CENTRIC | 120.62053, 121.62053, 125.62053, 126.62053CSL, 126.62053CSR, 126.62053SL, 126.62053SR, 127.62053L, 127.62053R, 128.62053L, 128.62053R, 227.62053L, 227.62053R |
| COMMAND AUTOMOTIVE | 107255 |
| CONTINENTAL-CONTITECH | CW20718 |
| Casting Numbers | 210625-C, 325269, 550171 |
| Centric Parts | 120.62053, 121.62053, 125.62053, 126.62053CSL, 126.62053CSR, 126.62053SL, 126.62053SR, 127.62053L, 127.62053R, 128.62053L, 128.62053R, 227.62053L, 227.62053R |
| DELPHI | RB558 |
| DURA CORP | BR55017 |
| DuraGo | BR55017 |
| EIS BRAKES | D17731 |
| EUROROTOR | 55120 |
| GM | 18018862, 18019852 |
| GREN | 670402 |
| GUARDIAN | 52-125417 |
| General Motors | 18018862, 18019852 |
| MAGMA PRODUCTS | PMR223056 |
| MIDAS | BR1982 |
| MIGHTY DISTRIBUTING SYSTEM | 55017 |
| MONROE BRAKES | BD125417 |
| NEWTEK AUTOMOTIVE | 55017 |
| Newtek Automotive USA | 55017 |
| PARTS MASTER | P125417 |
| PROMAX | 14-55017 |
| QUALIS | 55017 |
| QUALITY BRAND | 55017, Q4112 |
| STANDARD ROTORS AND DRUMS | 55017 |
| THE UNIVERSAL GROUP | 101270 |
| UAP | 55017 |
| Ultra Brake | 55120 |
| Universal | 101270 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51019 |
| WAGNER | BD125417 |
| WAGNER BRAKE | BD125417, SB56450 |
| WINHERE | 442325, YH2325 |
RAYBESTOS 56450R Fits Vehicles
- Chevrolet Commercial Chassis (1994)
- Chevrolet Impala (1994-1996)
- Chevrolet Caprice (1994-1996)
