BENDIX 800471 Part Description
Manufacturer
Product Description
Relay Valve
Features & Benefits
- Prevents one axle from under-braking relative to others
- Return spring resets the piston after each application
- Seal tolerances are rebuilt to match original new-valve calibration
- Exhausts pressure quickly the moment the pilot signal drops
Bendix Relay Valve
A trailer or pusher axle applying noticeably softer than the rest can point to a relay valve losing pressure, calling for the Bendix Relay Valve. The Bendix 800471 rebuilds that piston and seal assembly to the same tolerances as new, so output pressure matches pilot signal the way the system was calibrated. That rebuild matters because the piston should open fully in proportion to the pilot signal, and a worn or sticking one can restrict flow even under full signal pressure. A rebuilt relay valve brings that axle's brake force back in line with the rest.
BENDIX 800471 Specifications
Product Attributes
| Balance / Primary Service Port | 1/4-18 NPT |
| Body Configuration | 2 SUP / 2 DEL (H) |
| Cautionary Note(s) | Not applicable to this part |
| Control / Secondary Service Port | 1/4-18 NPT |
| Control Port Orientation (CW from Front Face) | 0Adeg |
| Crack Pressure | 5.5 PSI |
| Delivery Port 1 | 1/2-14 NPT |
| Delivery Port 2 | 1/2-14 NPT |
| Delivery Port 3 | Not applicable to this part |
| Delivery Port 4 | Not applicable to this part |
| Delivery Port 5 | Not applicable to this part |
| Delivery Port 6 | Not applicable to this part |
| Delivery Port 7 | Not applicable to this part |
| Delivery Port 8 | Not applicable to this part |
| Exhaust Port | Dust Shield |
| Internal Supply Passage to Cover | Not applicable to this part |
| Market Indicator | Aftermarket New |
| Maximum Operating Temperature | 200 AdegF (93 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting | .96 IN x .40 IN Slot (2x) |
| Mounting Bracket Direction | Not applicable to this part |
| Mounting Bracket Location | Loose in Box |
| Mounting Orientation (CW from Front Face) | Not applicable to this part |
| Supply Port 1 | 1/2-14 NPT |
| Supply Port 2 | 1/2-14 NPT |
| TMC Washer | RV055 |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 04068078307120 |
| VMRS Code | 013010009 |
BENDIX 800471 Cross References
| Brand | Part Number |
|---|---|
| BW800471 | |
| N/A | 5004910 |
| NABI | 6305428 |
