Centric 120.65132 - Centric Premium Brake Rotor
$9199
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 15.850 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 7.200 |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22.000 MM |
| Nominal Thickness | 24.000 MM |
| Nominal Thickness | 0.945 IN |
| Hat Finish | Coated |
| Overall Height | 1.752 IN |
| Overall Height | 44.500 MM |
| Outside Diameter | 278.000 MM |
| Outside Diameter | 10.945 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.500 IN |
| Center Hole Diameter | 63.500 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.800 MM |
| Stud/Lug Hole Diameter | 0.543 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890618034 |
Part Interchanges
- Raybestos Brakes 680765
- Raybestos Brakes 680765FZN
- Raybestos Brakes 680765R
- Neotek Premium Drums and Rotors 1071097GF
- E125-70-137
- BR90085002
- 75002GT
- YH286284
- 42269
- BRRF87
- 42269G
- 1361298
- 4367105
- 4455980
- 2T141125CB
- 2T141125EC
- 4367104
- 4367106
- 4457985
- 2T141125EB
- 2T141125CC
- 2T1Z1125A
- 75002
- 850170
- 880765
- DDF1172
- 2054172
- 90054217
- E12570137
CENTRIC 120.65132 Cross Reference
We have 5 alternatives for the 120.65132 by CENTRIC:
Fits Vehicles
- Ford Transit Connect (2010-2013)
