(888) 312-8812 Login SignupRAYBESTOS 9225R Raybestos R-Line Brake Rotor
$32.15
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 9225R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1981-1979 Nissan 280ZX Rear, 1981-1980 Nissan 200SX Rear, 1981 Nissan 810 Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 9225R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.678 IN |
| Center Hole Diameter | 68 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.338 IN |
| Discard Thickness | 8.6 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.502 IN |
| Mounting Bolt Hole Diameter | 12.75 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.38 IN |
| Nominal Thickness | 9.65 MM |
| Outside Diameter | 10.565 IN |
| Outside Diameter | 268.35 MM |
| Overall Height | 2.705 IN |
| Overall Height | 68.7 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352367971 |
RAYBESTOS 9225R Cross References
| Brand | Part Number |
|---|---|
| 829352367971 | |
| ADVANCE AUTO PARTS | 141181, YH141181 |
| AMERICAN REMANUFACTURED | 789-04014, 89-04014 |
| AUTOSPECIALTY | JBR160, JBR160E |
| AUTOZONE | 3197, 3197DG |
| AXXIS | 085-5330 |
| BECK/ARNLEY | 080-1750, 083-1750 |
| BENDIX | 141181 |
| BRAKE HEADQUARTERS | BR04083 |
| BRAKE PRO | 4619225 |
| BRAKEBEST | 9225, 9225R, 9225RGS, BD97313 |
| BREMBO | 08.4851.10, 25110 |
| CALIFORNIA DRUM & ROTOR | 97313 |
| CENTRIC | 120.42014, 121.42014, 126.42014SL, 126.42014SR, 127.42014L, 127.42014R |
| CENTURY | 9225 |
| CEW | 1163300 |
| Casting Numbers | 210366-C, 31971, 325663 |
| Centric Parts | 120.42014, 121.42014, 126.42014SL, 126.42014SR, 127.42014L, 127.42014R |
| DATSUN/NISSAN | 43206R4800 |
| DAYTON WALTHER | D7350 |
| DURA CORP | BR3197 |
| DuraGo | BR3197 |
| EIS BRAKES | D9225 |
| EUROROTOR | NI429 |
| FRATELLI POLETTI | 99YS |
| GIRLING | GR674 |
| GREN | 32001 |
| INTERBRAKES | NS191P |
| ITM ENGINE COMPONENTS | 1600505 |
| LAZORLITE | L73-1072 |
| MAGMA PRODUCTS | PMR423008 |
| MCI | 3978 |
| MIDAS | BR1213, BR1219 |
| MIGHTY DISTRIBUTING SYSTEM | 3197 |
| MOUNTAIN OFF-ROAD ENTERPRISES | NR21 |
| NEWTEK AUTOMOTIVE | 3197 |
| Newtek Automotive USA | 3197 |
| Nissan | 43206R4800 |
| QUALIS | 3197 |
| QUALITEE INTERNATIONAL | 64-76-210 |
| QUALITY BRAND | 3197 |
| ROADMATES | 526510 |
| SANYO | NR21 |
| STANDARD ROTORS AND DRUMS | 3197 |
| TEKNOMAC | 29160 |
| THE UNIVERSAL GROUP | 109970 |
| TRANSPARTS | BR0109 |
| TRUSTAR | 476210, R76210 |
| UAP | 3197 |
| Universal | 109970 |
| VERA | 3400686 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50338 |
| WAGNER | BD97313 |
| WAGNER BRAKE | BD97313 |
| WINHERE | YH1097 |
| WORLDPARTS | W70-516 |
RAYBESTOS 9225R Fits Vehicles
- Nissan Maxima (1981)
- Nissan 810 (1981)
- Nissan 280ZX (1979-1981)
- Nissan 200SX (1980-1981)
