RAYBESTOS 96073R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1995-1988 Isuzu Pickup Rear, 1991-1987 Isuzu Trooper Rear, 1993-1989 Isuzu Amigo Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 96073R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.8 IN |
| Center Hole Diameter | 96.5 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.417 IN |
| Discard Thickness | 10.6 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.493 IN |
| Mounting Bolt Hole Diameter | 12.5 MM |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 10.455 IN |
| Outside Diameter | 265.55 MM |
| Overall Height | 1.87 IN |
| Overall Height | 47.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 6 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352369708 |
RAYBESTOS 96073R Cross References
| Brand | Part Number |
|---|---|
| 829352369708 | |
| ADVANCE AUTO PARTS | 141416, YH141416, YH141416C |
| AMERICAN REMANUFACTURED | 789-10005, 89-10005 |
| AUTOSPECIALTY | JBR323, JBR323E |
| AUTOZONE | 31135, 31135B, 31135DG |
| BECK/ARNLEY | 080-2232, 083-2232 |
| BENDIX | 141416 |
| BRAKE HEADQUARTERS | BR14369 |
| BRAKE PRO | 4611323 |
| BRAKEBEST | 30010835, 96073, 96073R, 96073RGS, BD61973 |
| BREMBO | 08.6865.10, 25189 |
| BrakeBest | 66074RGS |
| CALIFORNIA DRUM & ROTOR | 61973 |
| CENTRIC | 120.43004, 121.43004, 320.43004 |
| CENTURY | 9444 |
| Casting Numbers | 210488-C, 211546-DP, 325030, 5148 |
| Centric Parts | 120.43004, 121.43004, 320.43004 |
| DELPHI | RB657 |
| DURA CORP | BR31135 |
| DuraGo | BR31135 |
| EIS BRAKES | D17492 |
| EUROROTOR | IS985 |
| GREN | 70801 |
| GUARDIAN | 52-61973 |
| GUNITE | G16045 |
| INTERBRAKES | BI041P |
| ISUZU | 8941732442 |
| MAGMA PRODUCTS | PMR325006 |
| MCI | 3957 |
| MIGHTY DISTRIBUTING SYSTEM | 31135 |
| MONROE BRAKES | BD61973 |
| NEWTEK AUTOMOTIVE | 31135 |
| Newtek Automotive USA | 31135 |
| PARTS MASTER | P61973 |
| QUALIS | 31135 |
| QUALITEE INTERNATIONAL | 64-73-130 |
| QUALITY BRAND | 31135, Q052 |
| QUINTON HAZELL | BDC3956 |
| STANDARD ROTORS AND DRUMS | 31135 |
| THE UNIVERSAL GROUP | 126300 |
| TRUSTAR | 473130, R73130 |
| UAP | 31135 |
| Universal | 126300 |
| VERA | 3405607 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50931 |
| WAGNER | BD61973 |
| WAGNER BRAKE | BD61973, SB96073 |
| WINHERE | YH1161 |
RAYBESTOS 96073R Fits Vehicles
- Isuzu Trooper (1987-1991)
- Isuzu Pickup (1988-1995)
- Isuzu Amigo (1989-1993)
