(888) 312-8812 Login SignupRAYBESTOS 96015R Raybestos R-Line Brake Rotor
MSRP: $36.00
$3249
Save $3.51
Limited availability at this price!
In Stock
Get as soon as Friday, Oct 2
RAYBESTOS 96015R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1994-1991 Mercury Capri Front, 1989-1986 Mazda 323 Front, 1989-1987 Mercury Tracer Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 96015R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.955 IN |
| Center Hole Diameter | 75.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.63 IN |
| Discard Thickness | 16 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 3.701 IN |
| Mounting Bolt Hole Circle Diameter | 94 MM |
| Mounting Bolt Hole Diameter | 3.701 IN |
| Mounting Bolt Hole Diameter | 94 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.71 IN |
| Nominal Thickness | 18.05 MM |
| Outside Diameter | 9.36 IN |
| Outside Diameter | 237.75 MM |
| Overall Height | 1.215 IN |
| Overall Height | 30.85 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352369357 |
RAYBESTOS 96015R Cross References
| Brand | Part Number |
|---|---|
| 829352369357 | |
| ADVANCE AUTO PARTS | 141436, YH141436 |
| AMERICAN REMANUFACTURED | 789-14018, 89-14018 |
| AUTOPART INTERNATIONAL | 78574 |
| AUTOSPECIALTY | JBR317, JBR317E |
| AUTOXTRA | 60839, AX3146 |
| AUTOZONE | 3146, 3146DG, DL3146 |
| BECK/ARNLEY | 080-2191, 083-2191 |
| BENDIX | 141436 |
| BOSCH | 20010439 |
| BRAKE HEADQUARTERS | BR08260 |
| BRAKE PRO | 4619746 |
| BRAKEBEST | 20010439, 81-60839, 96015, 96015R, 96015RGS |
| BREMBO | 09.5061.10, 25290 |
| BrakeBest | 66017RGS, 66018RGS, 6616RGS |
| Bridgestone | 7075388 |
| CALIFORNIA DRUM & ROTOR | 60839 |
| CENTRIC | 120.45018, 121.45018 |
| CENTURY | 9093 |
| Casting Numbers | 210525-C, 31461, 325060, 6853 |
| Centric Parts | 120.45018, 121.45018 |
| DAYTON WALTHER | D7948 |
| DELPHI | RB8 |
| DURA CORP | BR3146 |
| DuraGo | BR3146 |
| EIS BRAKES | D17272 |
| EUROROTOR | MA826 |
| FADE FREE | 60839 |
| FORD | E7GZ1125B |
| GIRLING | GR704, GR715, GR804 |
| GREN | 50502 |
| GUARDIAN | 52-60839 |
| HOLLANDER | 58141 |
| INTERBRAKES | MZ081V |
| ITM ENGINE COMPONENTS | 1601118 |
| MAZDA | B10733251, BF6833251A |
| MCI | 3928, 4042 |
| MIDAS | BR1518 |
| MIGHTY DISTRIBUTING SYSTEM | 3146 |
| MOTORCRAFT | BRR75 |
| NEWTEK AUTOMOTIVE | 3146 |
| Newtek Automotive USA | 3146 |
| PARTS MASTER | P60839 |
| QUALIS | 3146 |
| QUALITEE INTERNATIONAL | 64-74-240 |
| QUALITY BRAND | 3146 |
| QUINTON HAZELL | BDC3596 |
| ROADMATES | 526573 |
| ROCKHILL | 3146 |
| SEARS | 18106 |
| STANDARD ROTORS AND DRUMS | 3146 |
| THE UNIVERSAL GROUP | 112460 |
| TRUSTAR | 474240, R74240 |
| TRW | DF1964S |
| UAP | 3146 |
| Ultra Brake | MA-826 |
| Universal | 112460 |
| VERA | 3404429, 3405616 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50384 |
| WAGNER BRAKE | BD60839 |
| WINHERE | YH2055 |
RAYBESTOS 96015R Fits Vehicles
- Mazda 323 (1986-1989)
- Mercury Tracer (1987-1989)
- Mercury Capri (1991-1994)
RAYBESTOS 96015R Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 96015R Questions & Answers
No questions yet
Be the first to ask a question about this product!
