DELPHI TC6962 Ball Joint

★★★★★ (0)

$23.99

Limited availability at this price!

In Stock

Get as soon as Monday, Nov 30
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details

DELPHI TC6962 Part Description

Manufacturer

DELPHI

Product Description

Ball Joint

Features & Benefits

  • Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
  • Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
  • Delphi machines to micron tolerances to guarantee durability and smooth joint operation
  • Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
Ball Joint

DELPHI TC6962 Specifications

Product Attributes

Position(s)Front Lower
MaterialSteel
Maximum Outside Diameter1.850 IN
Maximum Outside Diameter47.00 MM
ColorBlack
Stud Thread Diameter12 MM
Castle Nut IncludedNo
Grease Fitting IncludedNo
Bushings IncludedNo
Dust Boot IncludedYes
Width47 MM
Cotter Pin IncludedNo
Cotter Pin HoleNo
Mounting Hardware IncludedYes
Mounting Bolt Length1.380 IN
Mounting Bolt Length35.00 MM
Washers IncludedYes
Height19.00 MM
Nuts IncludedYes
Mounting Hole Quantity2
AdjustableNo
GreaseableNo
Stud Thread Length1.38 IN
Stud TypeThreaded
Mounting TypeBolt-In
Distance Between Mounting Holes50.00 MM
Dust Boot MaterialRubber
Mounting Bolt Shank Diameter0.472 IN
Mounting Bolt Shank Diameter12.00 MM
Mounting Bolts IncludedYes
Mounting Bolt Thread Pitch1.25 MM
Mounting Bolt Thread Length1.380 IN
Mounting Bolt Thread Length35.00 MM
Mounting Bolt Thread Diameter12.00 MM
Mount Plate IncludedYes
Tapered StudYes
Stud Tapered End 2 Diameter0.59 IN
Stud Tapered End 2 Diameter14.9 MM
Stud Tapered End 1 Diameter0.68 IN
Stud Tapered End 1 Diameter17.3 MM
Stud Thread Pitch1.25 MM
Length4.000 IN
Length100.00 MM
Stud Thread Diameter0.47 IN
Height0.750 IN
Stud Thread Length35.05 MM
Mounting Bolt Thread Diameter0.470 IN

Additional Information

Harmonized Tariff Code (Schedule B)8708807000
Country of Origin (Primary)TR
Harmonized Tariff Code (HTS)8708806590
Warranty SpecialLimited
Warranty Special UOMLT
UPC00689604381854
VMRS Code016001015
UNSPSC25174203

DELPHI TC6962 Cross References

BrandPart Number
General Motors96535089
MOOG Chassis ProductsK500034
MevotechMS50505
N/AGS50505, BJ55005
TRWJBJ7561

DELPHI TC6962 Fits Vehicles

  • Chevrolet Aveo (2004-2011)
  • Chevrolet Aveo5 (2006-2011)
  • Pontiac G3 (2009-2010)
  • Pontiac G3 Wave (2009)
  • Pontiac Wave (2005-2008)
  • Pontiac Wave5 (2005-2007)
  • Suzuki Swift+ (2004-2010)
