WABCO 9617234110 - Parking Brake Valve - Hand Brake
$35899
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
WABCO part description
VALVE: HAND BRAKE - AIR
Product Attributes
| Weight | 1.2015 |
| Actuation Angle | 73° |
| Size | 96 x 225 x 111 |
| Max. operating pressure | 145.04 psi |
| Max. operating pressure | 145.04 psi |
| Port threads | M16 x 1.5 |
| Distance Between Holes | 80 mm |
| Mounting | M6 |
| Parking Position | 73° |
| Port thread 21 | M16 x 1.5 JED - 464 |
| Port thread 1 | M16 x 1.5 JED - 464 |
| Color | Black/Black |
| Temperature Range | -40°C to +80°C |
| Calculated Volume (dm³) | 2.3976 |
| Exhaust | Hose Nozzle Ø 6 mm |
| Type | vented |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
