TrakMotive TO-8144 - CV Axle Shaft
- Part Number
- TO-8144
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$11399
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 48 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .6 |
| Axle Nut Height (mm) | 15 |
| Axle Nut Hex Size (in) | 1.17 |
| Axle Nut Hex Size (mm) | 30 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 35 |
| Axle Nut Locking Type | Standard |
| Axle Nut Thread Size | M22x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 24 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 30 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 26.19 |
| Overall Compressed Length (mm) | 666 |
| Axle Nut Socket Size | 30 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084081445 |
Part Interchanges
- ARC 80-3766
- EMPI 80-6189
- Mevotech CV8963
- Carquest 410863
- USA Industries 7087739
- USA Industries AX-87739
- American Remanufactured 40-18793S
- Drive Tech America TO-8765A
- Fenwick CV1915
- CARDONE Reman 60-5205
- CARDONE Reman 605205
- OEM Part Number 4342006030
- OEM Part Number 4342006040
- OEM Part Number 4342006090
- OEM Part Number 4342006100
- OEM Part Number 4342006180
- OEM Part Number 434200618084
- ODM TO-8-8835A
- TrakMotive TO-8144
- 410863
- NCV69557
- 90622
- MX-18765S
- 329144
Fits Vehicles
- Toyota Solara (1999-2002)
- Toyota Camry (1997-2001)
