TrakMotive FD-8069 - CV Axle Shaft
- Part Number
- FD-8069
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$9349
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 0 |
| ABS Ring Type | N/A |
| Abs Tone Ring Included | No |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .89 |
| Axle Nut Height (mm) | 23 |
| Axle Nut Hex Size (in) | 1.14 |
| Axle Nut Hex Size (mm) | 29 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 34 |
| Axle Nut Locking Type | Stake |
| Axle Nut Thread Size | M20x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Male |
| Inboard Shaft Connection Style | Male |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 22 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 24 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 23.86 |
| Overall Compressed Length (mm) | 606 |
| Axle Nut Socket Size | 29 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084020697 |
Part Interchanges
- EMPI 80-2411
- Car Components Technologies (CCT) 8331
- Mevotech CV4033
- Carquest 410184
- USA Industries AX-6752
- American Remanufactured 40-19103
- Drive Tech America FD-9103
- Fenwick CV6752
- CARDONE Reman 66-2016
- OEM Part Number E8BZ3B437A
- OEM Part Number FOBZ3B437C
- ODM FD-8-8504
- TrakMotive FD-8069
- 410184
- NCV11063
- 71579
- 169069
Fits Vehicles
- Ford Festiva (1988-1993)
