CENTRIC 123.67034 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.67034 Specifications
Product Attributes
| Weight [cntrc] Kgs | 10.455 |
| Weight [cntrc] Lbs | 23.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 90.424 |
| Hub Hole / Register [cntrc] In | 3.560 |
| Height [cntrc] Mm | 103.378 |
| Height [cntrc] In | 4.070 |
| Friction Surface Width [cntrc] Mm | 74.676 |
| Friction Surface Width [cntrc] In | 2.940 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 282.300 MM |
| Maximum Brake Diameter (Discard) | 11.114 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 326.898 MM |
| Outside Diameter | 12.870 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.510 MM |
| Mounting Hole Diameter | 0.650 IN |
| Nominal Drum Diameter | 280.200 MM |
| Nominal Drum Diameter | 11.030 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890209805 |
CENTRIC 123.67034 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD125749, E127-72-039, E128-72-039, 80082, BD80082, 80082G, 52009541AB, 52009541AC, 52009541AD, 140724, PDR0724, 203312, 87672, AD8734, AD8734E, AD8736, E12350, E12772039, E12872039, 4317, 541, 2339506, 23110, 9672, 9672R, 9672DGS, 8840034, 8840036, 36540052 |
| PRONTO | BD80082 |
| RAYBESTOS | 9672, 9672R |
| WAGNER | BD125749 |
CENTRIC 123.67034 Fits Vehicles
- Dodge Ram 1500 Van (1999-2002)
- Dodge B1500 (1998)
