CENTRIC 123.67002 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.67002 Specifications
Product Attributes
| Weight [cntrc] Kgs | 12.045 |
| Weight [cntrc] Lbs | 26.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 120.650 |
| Hub Hole / Register [cntrc] In | 4.750 |
| Height [cntrc] Mm | 102.108 |
| Height [cntrc] In | 4.020 |
| Friction Surface Width [cntrc] Mm | 88.900 |
| Friction Surface Width [cntrc] In | 3.500 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 307.100 MM |
| Maximum Brake Diameter (Discard) | 12.090 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 357.124 MM |
| Outside Diameter | 14.060 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.764 MM |
| Mounting Hole Diameter | 0.660 IN |
| Nominal Drum Diameter | 304.800 MM |
| Nominal Drum Diameter | 12.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890053118 |
CENTRIC 123.67002 Cross References
| Brand | Part Number |
|---|---|
| 1345, 101345, 52-60302, 5260302, BD60302 | |
| N/A | BD60302, 52-60302, 5260302, BD125462, E127-72-007, E128-72-007, 8880, BD8880, D91 750, 63 91 750, 8880C, 8880CG, 111345, 4032856, 4036930, 2549826, 3491675, 4238192, 4238193, 3549826, 3549827, PDR0267, 140267, 203800, 440-1591, 6401111, 6401591, 824, AD8702, AD8702E, D5964, E9234, E12772007, E12872007, 95961, 87345, X21545, 23031, BD1030, 101345, 1345, 1345R, 1345DGS, 8840002, 78-40002, 7840002, 78840002, 68330, 36540024, 177271 |
| PRONTO | BD8880 |
| RAYBESTOS | 1345, 1345R |
| WAGNER | BD60302 |
CENTRIC 123.67002 Fits Vehicles
- Dodge P200 (1972)
- Dodge P200 Van (1972-1974)
- Plymouth PB300 Van (1974)
- Dodge W200 Pickup (1972-1974)
- Dodge D200 Pickup (1970-1974)
- Dodge B300 Van (1971-1974)
- Plymouth PB350 (1981-1983)
- Plymouth PB300 (1975-1980)
- Dodge W350 (1984-1993)
- Dodge W250 (1981-1993)
- Dodge W200 (1975-1980)
- Dodge D350 (1982-1993)
- Dodge D250 (1981-1993)
- Dodge D200 (1975-1980)
- Dodge B3500 (1995-1997)
- Dodge B2500 (1995-1997)
- Dodge B250 (1994)
- Dodge B350 (1981-1994)
- Dodge RD200 (1978-1980)
- Dodge B300 (1975-1980)
